Version history
Version history
I-jet®
12
User Guide
JTAG VTref measurement resolution
Current draw from VTref
I-jet comes with a 20-pin MIPI connector (0.05 in × 0.05 in pitch) on the front panel. It
includes two cables:
A 6-inch cable with 20-pin MIPI connectors on both ends for the Cortex-M targets
●
with 20-pin MIPI headers. Pin 7 on each end is keyed with a white plug.
A 6-inch cable with 20-pin MIPI connectors on one side (to connect to I-jet), and
●
10-pin MIPI connector on the other side for connection to Cortex-M targets with
10-pin headers. Pin 7 on each end is keyed with a white plug.
These are the versions of I-jet:
Version A
~2 mV
< 50 μA
The first version.
