Model specifications

Technical specifications

This chapter provides technical specifications for the I-jet In-Circuit Debugger.
More specifically, this means:
Model specifications
●
Version history
●
Target interface
●
Indicators
●
Adapters.
●
These are the specifications of I-jet:
USB speed
USB connection
JTAG connection
Adapters included
I-jet debug interface
JTAG/SWD maximum clock
SWO protocols supported
SWO maximum clock speed
Power supplied to target
Over-current protection
Target power measurement resolution
Target power measurement speed
JTAG voltage range (auto-sensing)
480 Mbps (USB 2.0)
Micro-B
MIPI-20, MIPI-10
ARM-20
JTAG and SWD
32 MHz
Manchester and UART
60 MHz
420 mA max at 4.4 V-5 V
520 mA (± 1%)
~160 μA
up to 200 ksps (kilo samples per second)
1.8 V to 5 V (± 10%)
