Arris SURFboard SBG6950AC2 Quick Start Manual
Wi-fi cable modem
Hide thumbs
Also See for SURFboard SBG6950AC2:
- User manual (63 pages) ,
- Quick start manual (52 pages) ,
- Quick start manual (28 pages)
Subscribe to Our Youtube Channel
Related Manuals for Arris SURFboard SBG6950AC2
Summary of Contents for Arris SURFboard SBG6950AC2
- Page 1 Q U IC K START GUI D E Wi-Fi Cable Modem SBG6950AC2 SBG6950AC2 SBG7400AC2 SBG7400AC2 SBG7600AC2 SBG7600AC2...
-
Page 2: Table Of Contents
Get started Quick Start Guide SBG6950AC2 SBG7400AC2 Set up your Wi-Fi network connection SBG7600AC2 Software License 3.1 Download ARRIS SURFboard® Manager mobile app & Warranty card 3.2 Connect using your Wi-Fi enabled device Wi-Fi cable modem Web Manager SBG6950AC2 SBG7400AC2... - Page 3 Status indicators Front panel LEDs...
-
Page 4: Led Status Indicators
5 GHz wireless connection is made 5 GHz between the Wi-Fi cable modem and Wireless your Wi-Fi device Note: Detailed LED status information is available online in the SBG6950AC2, SBG7400AC2, & SBG7600AC2 User Guide at the ARRIS support website, www.arris.com/selfhelp. -
Page 5: Get Started
Get started This SURFboard device is a combination of DOCSIS 3.0 cable modem and four-port Ethernet router with Wi-Fi. It uses DOCSIS 3.0 technology to provide ultra high-speed Internet access on your Wi-Fi home or small business network. Using the connection capabilities of the Wi-Fi cable modem, you can connect your computer and other network-enabled devices via the four Ethernet ports or the 2.4 GHz and 5 GHz Wi-Fi connections. - Page 6 a coaxial cable (not included) to a cable wall Connect outlet or an RF splitter (not included) and to the Cable connector on the rear of your Wi-Fi cable modem. Tighten the connector by hand.
- Page 7 the power adapter to the Power port on the (Optional step) Connect an Ethernet cable (not Connect rear of your Wi-Fi cable modem and then plug it into included) to any Ethernet port on the rear of your an electrical wall outlet that is not controlled by a wall Wi-Fi cable modem and the Ethernet port on your PC switch to power on your Wi-Fi cable modem.
- Page 8 Note: For Internet access, you will need a cable service the front panel LEDs on your Wi-Fi cable Check connection. modem. After a brief pause, the first three LEDs should light up SOLID blue. Activate your new Wi-Fi cable modem; choose one of the following options: •...
-
Page 9: Set Up Your Wi-Fi Network Connection
Set up your Wi-Fi network connection Download ARRIS SURFboard® Manager mobile app Download the iOS or android version of the ARRIS Do the following to set up your Wi-Fi network SURFboard Manager mobile app for your iOS or connection: android Wi-Fi enabled device to set up your Wi-Fi ®... - Page 10 ARRIS SURFboard Manager mobile app (see the ARRIS SURFboard Manager mobile Download app from the Apple app store or Google play store. page 19) or the Web Manager for your SBG6950AC2, SBG7400AC2, or SBG7600AC2 (see page 25) to Scan the SURFboard Manager mobile app QR code...
-
Page 11: Connect Using Your Wi-Fi Enabled Device
the Settings screen on your Wi-Fi enabled Access device and then select: Wi-Fi, Wireless, or Connections. that Wi-Fi or Wireless is set to ON. Check Connect using your Wi-Fi enabled device Some of the selections used in this procedure may vary slightly depending on your Wi-Fi enabled device and operating system. - Page 12 your Wi-Fi network password in the Password Enter the SBG6950AC2, SBG7400AC2, or Select field and select Join or Connect. SBG7600AC2 Wi-Fi network from the list of This is available Wi-Fi networks. the password that you set up during the Wi-Fi cable modem activation.
-
Page 13: Web Manager
Web Manager your SBG6950AC2, SBG7400AC2, or Manage SBG7600AC2 using the Web Manager. Open a web browser (e.g., Internet Explorer, Google Chrome, etc.) on your connected computer or laptop and then type 192.168.0.1 in the address bar. The default login is case-sensitive: User name: admin Password: password Change... - Page 14 Web Manager. For additional assistance with your Wi-Fi cable modem, ARRIS is available to help. Choose one of the following: Visit any public web page such as www.surfboard.com. If the web site fails to open, please contact your service...
- Page 15 © 2020 CommScope, Inc. All rights reserved. ARRIS and the ARRIS Logo are trademarks of CommScope, Inc. and/or its affiliates. All other trademarks are the property of their respective owners. No part of this content may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from CommScope, Inc.
