SUNSTONE Ruby Companion Pro Instructions Manual page 9

GRILL INSTALLATION – PRODUCT DETAILS
Technical Measurements
If you are installing grill into cabinet structure you may need to refer to these engineer dimensions
specifically the grill firebox dimensions. (Measurements were obtained from engineer drawing. margin of
error is within 1/8" to actual product)
Product Size
Overall Width--------------------
Overall Height-------------------
Overall Depth--------------------
Firebox Size – See next page
13"
Box Width (includes brackets) 10-1/4"
12-3/4"
Box Height----------------------
26"
Box Depth (includes flange) 22-1/2"
PAGE 5
9-3/4"
