Danfoss ERC 213 Quick Start Manual

Quick Start Guide
ERC 213
Overview
The ERC 213 is designed to be an easy, universal replacement control. We encourage users to employ one of five predefined applications that meet the
needs of most systems. If users need to modify specific parameters, it should be done after installing the predefined application that most closely meets
system needs.
For more information, including detailed instructions, error codes, parameters, and more,
visit www.danfoss.com/erc or download the Koolcode app from iTunes or Google Play.
For a video guide of the quick set-up, visit http://bit.ly/ERC213 or use the QR code located to the right.
Quick Set-up
STEP Action
STEP 1 Wire control, to include power and sensors
Power up control
STEP 2
Energize control
Enter Quick Configuration Menu and Select app
Press "<" for more than three seconds within one minute of power up to enter Quick Configuration Menu. o61 appears on screen
STEP 3
Press "set" while o61 is on screen
Select appropriate app using App Selection section below by pressing " " or " ", then press "set".
Select Sensor
Press "set" while o06 is on screen
STEP 4
If using included sensor, leave default value "n10". If using another sensor, select using Sensor Resistance
section on opposing page or cycle through steps 2 – 4 changing the sensor type until the temperature reading
on the main screen is accurate. As above, cycle between options by pressing " " or " " and press "set" to save.
Set Temperature
STEP 5 From main screen, quickly press "set" (1 second).
Cycle to intended temperature by pressing " " or " " and press "set" to save.
App Selection
Select application based on application and wiring configuration (i.e., refrigeration vs. freezing, and number of temperature sensors). The Typical Wiring
Configurations diagram on the reverse side of this document may be used to assist with selection. All parameters can be modified using the full menu.
Some parameters have min and max set points which may need to be changed for less common configurations.
Control
Application Application
Code
AP0 (Default) No preset application - full menu
AP1 Refrigeration
AP2 Refrigeration
AP3 Freezing
AP4 Refrigeration
AP5 Freezing
AP6 No preset application - simplified menu
* Hot gas defrost is an option available in full menu (d01).
Key Functions and Display Icons
Key Functions
Press and hold at power up:
FACTORY RESET ("FAC" is
displayed)
Press for one second: BACK
Press and hold: PULL-DOWN
Display Icons
Night mode (Energy saving)
Compressor running (Flashes
in pull-down mode)
Defrost
© Danfoss | DCS (ADAP-KOOL®) | 2018-11
Defrost Defrost
Sensors
Type* Termination
2
Natural Time 1
Electric Time 1
Electric Time 1
Electric Temp. 2
Electric Temp. 2
2
Press for one second: UP
Press and hold: ON / OFF
Press for one second: DOWN
Press and hold: DEFROST
Press for one second: TEMP. SETPOINT / OK
Press and hold: MENU
SET
Fan running
Active alarm
°C Unit (°C or °F)
Temp. Range
Default
min. / max. Default Dif.
Temp. [°F]
[°F] [°F] [r01]
[r00]
[r02/r03]
36 -31 / 22
39 36 / 43
36 32 / 39
-11 -15 / -4
36 32 / 39
-11 -15 / -4
36 -31 – 122
Connection Diagram
DO1
3L
1 2
~ ~ ~
Power supply
(according to the product code number)
– Sair Control sensor
– S5 Defrost (evaporator) sensor
– SC Condenser sensor
– DI1 Digital input – configurable to the functions listed under
menu code o02
– DI2 Digital input – configurable to the functions listed under
menu code o37
Screen Display
Control turns on, goes through start up,
then shows the current temperature reading
AP0 flashes on screen
o06 appears on screen
n10 flashes on screen
o06 appears on screen, then control resets
Current temp. setting appears on screen
Screen returns to main screen
Defrost Max.
Interval Defrost
[hrs] Time [mins]
[d03] [d04]
4 6 30
4 4 30
4 6 15
4 6 15
4 6 30
4 6 30
4 6 30
Programming key – EKA 183B (080G9741)
GND TX RX +5V
DO2 DO3
15 16 17 18
GND GND
4N 9 10 11 12 13
5 6 7 8
~
Sair S5 Sc/DI1
DKRCE.PD.RL0.A3.02 | 1
Defrost
Termination
Temp. [°F]
[d02]
43
–
–
–
43
43
43
14
DI2
