Do not hesitate to contact him in case of doubt. Electrical connection ...................27 Pre-testing and final inspection ............33 Checking the operation and first start-up ........33 CUPPONE 1963 Cuppone F.lli S.r.l. Via Sile, 36 31057 Silea (TV) - ITALY T +39 0422 361143 F +39 0422 360993 info@cuppone.com - www.cuppone.com...
CHECKS BEFORE PURCHASING Before purchasing the oven and before its installation, check and agree with the owner that, on installation, all the following conditions are met; they are indispensable for the correct and safe installation, operation and maintenance of the oven. Check with the owner if in the place of installation there are the tools to handle the oven easily Fig.
Page 4
Checks before purchasing Survey the installation room to make sure it is Inform the owner about the necessary electrical • it is possible to maintain a minimum distance between adequate. arrangements (activities to be carried out by a the oven and the walls, other equipment, objects...
Page 5
Checks before purchasing ø150 mm [Ø 5.91 in.] Evacuation tube (NOT supplied) Max 35°C Max 95°F Min 5°C Max 70% Min 41°F °C 400 °C 400 not supplied not supplied Fig. 2 min. 50 mm [ 1,97 in.] extraction min. min.
OVEN TECHNICAL DATA Electrical data VALUES FOR EACH INDIVIDUAL CHAMBER Power supply Power Average Absorption Connection cable* Customer panel protection* Model [Kw] consumption [kWh] [Nxmm2] [NxA] 230V 23.0 3x2,5 2x25 3Nx400V 4x16 PAOLO 3x230V 13.3 4x1,5 3x16 3x208V 16.0 4xAWG15 3x16 230V 33.9...
INSTALLATION Symbols used in the manual and on Safety instructions • Before performing any maintenance, replacing components or carrying out any routine/ the labels applied to the machine • Read this guide carefully before installing the extraordinary cleaning, disconnect the electricity appliance, and keep it with care in an accessible supply.
Installation Transport Fig. 5 Fitted with personal protection equipment, transport the appliance to the installation location. Use a suitable vehicle capable of withstanding the weight of the same. Model single double Model single double 122 kg 209 kg 159 kg 278 kg PAOLO TP635L...
Installation Positioning min. Fig. 8 50 mm The positioning room must comply with the instructions pro- [ 1,97 in.] vided on page and 5. Comply with the measure- ments shown in the figure. min. min. 50 mm 500 mm Fig. 9 [ 1,97 in.] [ 19,7 in.] The oven must be placed on a base, built by the Manufacturer...
Installation Serial number plate reading Year of production Fig. 10 Model The serial number is on the right hand side of the appliance. It provides important technical information that is vital in case of a request for maintenance or repair of the appliance: please do not remove, damage or modify it.
Installation Electrical connection Fig. 12 Fig. 12 The electrical connection must be carried out exclusively by qualified personnel after reading the safety warnings at the beginning of the manual. Before installing the appliance, check that systems comply with the regulations in force in the country where it is going to be used and with the specifications...
Page 28
Installation • must be connected to an omnipolar circuit breaker allowing complete disconnection in overvoltage III category conditions. The Manufacturer accepts no liability for failure to comply with the above. °C 400 If required, the cable can be replaced by the Dealer or its °C 400 technical service or by a person with similar qualifica- 20 0...
Page 29
Installation AC 230 °C Abbreviation Description Fuses Contactor Safety contactor Warning light 400V Cooking chamber lights Cooling fan Top element switch Top element switch RA1,2,3 Top heating elements RB1,2,3 Bottom heating elements Rotary disconnector Master switch Light switch Safety thermostat Element thermostat Terminal board Transformer 25VA, 230/12V AC...
Page 30
Installation AC 3 230 °C Abbreviation Description Fuses Contactor Safety contactor Warning light 400V 230 Vac 50/60 Hz Cooking chamber lights 0,11/0,09 A Cooling fan Top element switch Top element switch RA1,2,3 Top heating elements RB1,2,3 Bottom heating elements Rotary disconnector Master switch Light switch Safety thermostat...
Page 31
Installation AC 3 N400 °C Abbreviation Description 10nF - 275V capacitor Fuses Contactor Safety contactor Warning light 230V Cooking chamber lights Cooling fan Top element switch Top element switch RA1,2,3 Top heating elements RB1,2,3 Bottom heating elements Rotary disconnector Master switch Light switch Safety thermostat Element thermostat...
Page 32
Installation AC 3 208 °C Abbreviation Description Fuses Contactor Safety contactor Warning light 400V Cooking chamber lights Cooling fan Top element switch Top element switch RA1,2,3 Top heating elements RB1,2,3 Bottom heating elements Rotary disconnector Master switch Light switch Safety thermostat Element thermostat Terminal board Transformer 50VA, 230/12V AC...
Installation Pre-testing and final inspection √ Positioning checks The oven is checked and tested in the Manufacturer’s plant Is the installation room adequate and compliant with regulations? (correct ventilation, maximum/minimum temperature, before being delivered to the customer. etc.) The “production process check sheet” enclosed with it Is the appliance perfectly level? each guarantees that...
