4k bullet
AI-BASED CAMERA
Qualcomm products contained herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated.
Advertisement
Table of Contents
Related Manuals for Bkav AIView S201
Summary of Contents for Bkav AIView S201
- Page 1 4k bullet AI-BASED CAMERA Qualcomm products contained herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated.
- Page 2 INSTALLATION GUIDE Model: S201 Product Number: 0803F/0802N...
-
Page 3: Product Kit
PRODUCT KIT Camera Wall bracket Rubber pad WALL DECAL FOR DRILLING POSITION Ø10 mm, 3 holes 4k bullet AI-BASED CAMERA Qualcomm products contained herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated. - Page 4 PRODUCT KIT GPS antenna Hex socket head screws Set 3 of screws Hex tool and anchors Waterproof couplings Safety cable...
-
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS PoE IEEE 802.3af/802.3at Power supply Maximum input 30W Protection standards IP66, IK10 Resolution, frame rate UHD 3840 x 2160, 60 fps S201-0803F: 3x Optical zoom S201-0802N: 2x S201-0803F: 10.9 - 29mm ± 5% Focal length S201-0802N: 4.36 - 9.33mm ± 5% S201-0803F: Near: 42°... -
Page 6: Product Overview
PRODUCT OVERVIEW Sunshield Dust and waterproof lens protector Camera lens Infrared LED Pivot point Wall bracket Waterproof coupling PoE cable... - Page 7 INSTALLATION GUIDE Step 1: Fix the bracket onto the wall with the anchors and screws (Figure 1). Step 2: Fix the camera onto the bracket and screw it in the place (Figure 2). Drilling position decal...
- Page 8 INSTALLATION GUIDE Step 3: Insert security cable onto bracket and camera (Figure 3). Step 4: Fix the security cable with screw onto bracket and camera (Figure 4).
- Page 9 ADJUSTING THE CAMERA VIEWING ANGLE Use hex tool to loose the screw on camera bracket to adjust the camera's angle. 90° 180°...
- Page 10 THE MEMORY CARD AND RESET INSTALLATION Reset installation: Open the protective cover that protects the camera against dust and water to reset the device. Memory card: Open the protective cover, you can find the location of Micro SD card. Reset installation Mirco SD card Note: Power off the camera, press and hold the factory reset button.
-
Page 11: Accessing The Camera
ACCESSING THE CAMERA Password setting Using your web browser, access the camera's default IP: 192.168.1.168 Note: To complete the installation steps for the camera, refer to the User Manual. The system will ask you to reset the password on your initial access. When the "Administrator password change"... -
Page 12: Software Installation
SOFTWARE INSTALLATION Login screen When accessing the camera, a login window will appear. Enter your user name and password to access the camera. 1. Enter "admin" in the <User name> box. 2. Enter your chosen password in <Password> box. 3. Click User name Password... -
Page 13: Safety Information
Improper installation may cause damage to the product. Contact Bkav's customer support or authorized Bkav agents if you experience any problems. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. - Page 17 BKAV CORPORATION Address: 2nd Floor - HH1 Building, Yen Hoa Ward, Cau Giay District, Ha Noi, Viet Nam Website: www.aiview.ai Email: aiview@bkav.com...
