- Page 1 BPC(I)-8 onCue Basic Presentation Controller ® Supplemental Guide Crestron Electronics, Inc.
- Page 2 United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
-
Page 3: Table Of Contents
Contents Introduction Applications Configuration Configuration Files ....................2 Button Caps ......................3 Operation Basic Control ......................4 Advanced Control ....................5 Contents • i Supplemental Guide – DOC. 7100C... -
Page 5: Introduction
The BPC-8 and the BPCI-8 can also be configured to control a complete room presentation system equipped with a display device, a motorized screen or lift, and a controllable source such as a DVD player. -
Page 6: Applications
The files are first uploaded to the handheld IR Learner & Programmer BPC-HPLIR (sold separately). The BPC-HPLIR is then used to upload the files to the BPC-8 via the supplied optical cable (refer to the following diagrams). Using this method, the user can add control for any device that uses an IR remote, including projectors, displays, and DVD players. -
Page 7: Button Caps
Configuration files developed for the BPC-8 typically require the button caps to be changed or rearranged on the unit. The following figures illustrate the preinstalled button caps, the five additional button caps supplied with the BPC-8, and the twelve button caps in the Accessory Kit (sold separately). -
Page 8: Operation
BPC-8 memory. NOTE: If a display device is not stored in the BPC-8, use the BPC-HPLIR IR Learner & Programmer (sold separately) to develop a program for the device. For more information, refer to the latest version of the BPC-HPLIR Supplemental Guide (Doc. 7109) at www.crestron.com/manuals. -
Page 9: Advanced Control
2. Upload the configuration to the BPC-HPLIR. 3. Connect the BPC-HPLIR fiber cable to the port on the bottom right of the BPC-8. 4. Press TRANSFER on the BPC-HPLIR. This method allows the user to add control for any device that uses an IR remote, including projectors, displays, and DVD players. - Page 10 Crestron Electronics, Inc. Supplemental Guide – DOC. 7100C 15 Volvo Drive Rockleigh, NJ 07647 (2029035) Tel: 888.CRESTRON 09.16 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
