Crestron FT2A-CBLR-BRKT-1200 Quick Start

FT2A-CBLR-BRKT-1200/FT2A-CBLR-BRKT-1400
Front/Rear Bracket for Two Cable Retractors for FT2-1200 and FT2-1400 Series
The Crestron® FT2A-CBLR-BRKT-1200 and FT2A-CBLR-BRKT-1400 brackets mount below
the surface to the front or rear face of the FT2-1200 series and FT-1400 series of FlipTop™
Cable Management Systems, respectively. Each bracket provides slots to accommodate up
to two cable retractors and one power supply holder. The bracket enables cable retractors to
occupy the center module positions inside the FlipTop.
Check the Box
Item
FT2A-CBLR-BRKT-1200 or FT2A-CBLR-BRKT-1400 (P/N 6510689 or 6510688)
Bracket, 9" x 3.6"
Screw, 10-32 x 5/16", SEMS, Pan Head, Phillips (P/N 2007287)
Install the Bracket
NOTE: Up to two brackets (front and rear) can be installed on the larger FT2-1400 series
FlipTop. A single bracket can be installed to either the front or rear of the FT2-1200 series
FlipTop.
Determine whether to install the bracket to the front or rear face of the FlipTop. Using a
#2 Phillips screwdriver, position the bracket against the FlipTop and secure with two screws
(provided). Use the following drawings for visual reference.
Front Bracket Installation - FT2-1200 Series FlipTop
(2) Screws Bracket
(included) (included)
Qty
1
2
FT2-1200 Series
FlipTop
Rear Bracket Installation - FT2-1200 Series FlipTop
FT2-1200 Series Bracket
FlipTop (included)
Front Bracket Installation - FT2-1400 Series FlipTop
(2) Screws Bracket
(included) (included)
Quick Start
(2) Screws
(included)
FT2-1400 Series
FlipTop
