Page 1 921 Corporate Way, Fremont, CA 94539, USA Tel: +1-510-490-8024 Fax: +1-510-623-7268 Web: http://www.actisys.com, E-mail: irda-info@actisys.com ACTiSYS ACT-IR4000US Series User’s Manual WARNING Please install driver BEFORE you plug in ACT-IR4000US to your computer USB port. uly 8,2008 Version 1.6.0.1 Copyright (C) 2002-2008 ACTiSYS Corp. All Rights Reserved...
Page 2 Please retain this information. Model Number Date of Purchase All indicated copyrights and trademarks in the following pages are copyrights and trademarks of their respective corporations. © Copyright 2002-2008 ACTiSYS Corp. Serial Number Place of Purchase Page 2 of 21 User’s Manual Jul 8, 2008 Version 1.6.0.1...
Page 3: Table Of Contents
PACKAGING CHECK LIST ... 5 SYSTEM REQUIREMENTS ... 5 BIOS SETUP... 5 ACT-IR4000US DRIVER INSTALLATION FOR WINDOWS 2000/ME/98SE... 6 ACT-IR4000US DRIVER INSTALLATION FOR WINDOWS XP ... 9 ACT-IR4000US WINDOWS XP NATIVE DRIVER REMOVAL PROCEDURE. 13 ACT-IR4000US DRIVER REMOVAL PROCEDURE FOR WINDOWS XP/2000/ME/98SE... 16 DRIVER INSTALLATION FOR VISTA ...
Page 4: Revision History
ACTiSYS reserves the right to make changes without further notice to any products herein to improve reliability, function or design. ACTiSYS does not assume any liability arising out of the application or use of any product or circuit described herein.
Page 5: Overview
The Wireless Connectivity Expert 1. OVERVIEW ACTiSYS IR4000US is an advanced wireless Fast Infrared USB adapter designed to replace the serial port or FIR controller-based FIR/SIR wireless peripheral through the PC USB port. Taking advantage of the true plug-and-play nature and the high bandwidth of USB, IR4000US offers the easiest conversion of existing wireless to the legacy-free personal computer platform with the following features: Fully compliant to USB specification 1.1 and IrDA...
Page 6: Act-Ir4000Us Driver Installation For Windows 2000/Me/98Se
A. Insert the attached CD to CD-ROM, Windows will display install manual. Please click Installation then it will execute InstallShield Wizard. Click on Next to continue. B. The Installer will install ACT- IR4000US in the Destination Folder. To install to a different folder, click Browse and select one. To continue, click on Next.
Page 7 The Wireless Connectivity Expert C. To complete the installation, Click on Finish to continue. D. You need to restart your computer. Select “Yes” and click Finish to reboot. © Copyright 2002-2008 ACTiSYS Corp. Page 7 of 21 Jul 8, 2008...
Page 8 E. After reboot, plug the ACT-IR4000US into the USB port. It will pop up a “Found New Hardware” window and install the detected drivers as follows: F. After this “ACTiSYS ACT-IR4000U Series” installation complete, it then completes the whole installation.
Page 9: Act-Ir4000Us Driver Installation For Windows Xp
Important: Do use Windows’ Native Driver. Please assure a smooth installation. If you have plugged IR4000US into USB port and mistakenly loaded WindowsXP Native Driver, please refer to Chapter 7 “ACT-IR4000US Windows XP Native Driver Removal Procedure” to remove the driver and then refer back to this Chapter to re-install the correct driver.
Page 10 User’s Manual The Wireless Connectivity Expert C. Click on Continue Anyway to continue. D. Insert the ACTiSYS ACT- IR4000US Series into the USB Jack and click on Finish. © Copyright 2002-2008 ACTiSYS Corp. Page 10 of 21 Jul 8, 2008...
Page 11 The Wireless Connectivity Expert E. Windows XP will detect ACTiSYS ACT-IR4000US Series. Select Install the software automatically (Recommended). Please note that you should take the CD out of the CD-ROM BEFORE clicking on Next. Note: If you keep the CD in the CDROM, Windows XP will automatically search for all drivers compatible with IR4000US.
Page 12 ACT-IR4000US Series User’s Manual The Wireless Connectivity Expert G. Click on Finish to complete the installation. © Copyright 2002-2008 ACTiSYS Corp. Page 12 of 21 Jul 8, 2008 Version 1.6.0.1...
Page 13: Act-Ir4000Us Windows Xp Native Driver Removal Procedure
The Wireless Connectivity Expert 7. ACT-IR4000US WINDOWS XP NATIVE DRIVER REMOVAL PROCEDURE Your ACTiSYS ACT-IR4000US is shipped with the latest driver on the CD. If you had already installed the Windows XP Native Driver, the following steps will tell you how to...
Page 14 C. Then you need to follow next step to remove it before go back to install the correct driver from installation CD. D. Right click on “SigmaTel USB-IrDA Dongle”. © Copyright 2002-2008 ACTiSYS Corp. Click on Uninstall. Page 14 of 21 User’s Manual...
Page 15 You have successfully removed the Windows XP Native Driver for the USB Infrared Adapter. Before PC restarting, you should connector from the PC’s USB “ACT-IR4000US DRIVER INSTALLATION For WINDOWS XP” to install the correct driver after PC restarted. © Copyright 2002-2008 ACTiSYS Corp. un-plug your ACT-IR4000US USB port.
Page 16: Act-Ir4000Us Driver Removal Procedure For Windows Xp/2000/Me/98Se
The Wireless Connectivity Expert 8. ACT-IR4000US DRIVER REMOVAL PROCEDURE FOR WINDOWS XP/2000/ME/98SE Important: Please keep the ACTiSYS ACT-IR4000US Series plugging into the computer until prompted to remove it. A. Open Control Panel and select Add / Remove Programs. Select ACTiSYS ACT-IR4000US Series from the list.
Page 17: Driver Installation For Vista
The Wireless Connectivity Expert C. To continue, click the Yes button to uninstall the ACTiSYS ACT-IR4000US Adapter. D. To complete the removal process, unplug the ACTiSYS ACT-IR4000US Series from your USB jack. Then click the Finish button. 9. DRIVER INSTALLATION FOR VISTA Since Vista has already had its local driver for this dongle, you can just directly enjoy plug &...
Page 18: Trouble Shooting
The device work well before. But after I unplug it then plug, it does not work again. © Copyright 2002-2008 ACTiSYS Corp. PROBLEM 1. The two IR devices are not aligned properly. 2. Distance is too near or far.
Page 19: Precautions
Never touch the pins of computer connection terminal. The internal circuits can be damaged by a Electro Static Discharge. If this device requires any servicing, use only an ACTiSYS service dealer, an ACTiSYS approved service facility, or an ACTiSYS repair service.
Page 20: Warranty Information
12. WARRANTY INFORMATION ACTiSYS Corporation warrants the first end-user purchaser, for a period of 1 year from the date of purchase, that this wireless interface (The Product) will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof at no charge to the purchaser for parts or for labor.
Page 21: Contact Information
User’s Manual The Wireless Connectivity Expert 13. CONTACT INFORMATION ACTiSYS Corporation 921 Corporate Way Fremont, CA 94539, USA TEL: +1-510-490-8024, FAX: +1-510-623-7268 E-Mail: irda-info@actisys.com Web: http://www.actisys.com © Copyright 2002-2008 ACTiSYS Corp. Page 21 of 21 Jul 8, 2008 Version 1.6.0.1...
