The Wireless Connectivity Expert
921 Corporate Way, Fremont, CA 94539, USA
Tel: +1-510-490-8024
Web: http://www.actisys.com
ACT-IR100M/IR100MP
®
IrDA
Printer Adapter
User's Manual
March 24, 2008
Version 3.2.2.1
© Copyright 1999-2008 ACTiSYS Corporation
All Rights Reserved
Fax: +1-510-623-7268
E-mail: irda-info@actisys.com
Advertisement
Table of Contents
Related Manuals for ACTiSYS IR100M
Summary of Contents for ACTiSYS IR100M
- Page 1 The Wireless Connectivity Expert 921 Corporate Way, Fremont, CA 94539, USA Tel: +1-510-490-8024 Web: http://www.actisys.com ACT-IR100M/IR100MP ® IrDA Printer Adapter User’s Manual March 24, 2008 Version 3.2.2.1 © Copyright 1999-2008 ACTiSYS Corporation All Rights Reserved Fax: +1-510-623-7268 E-mail: irda-info@actisys.com...
- Page 2 Date of Purchase All indicated copyrights and trademarks in the following pages are copyrights and trademarks of their respective corporations. © Copyright 1999-2008 ACTiSYS Corp. Class category (information equipment to be used in a residential Serial Number Place of Purchase...
-
Page 3: Important - Compatibility List
O.S. and therefore, not compatible with MFP. However, there are some exceptions, such as Brother MFC4350 and other brands/models." IR100M series compatible with any interface of IEEE 1284 Type B. If printer is equipped with 2 interfaces, ONLY 1 interface could work at a time. Both interfaces can’t work simultaneously. -
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS IMPORTANT - COMPATIBILITY LIST...3 REVISION HISTORY ...5 1. INTRODUCTION ...6 2. ACT-IR100M LED BEHAVIOR...6 3. ACT-IR100MP LED BEHAVIOR...7 4. PARTS CHECK LIST...8 5. SYSTEM REQUIREMENTS ...8 6. SETUP PROCEDURE ...9 7. TROUBLE SHOOTING ...11 8. -
Page 5: Revision History
ACTiSYS reserves the right to make changes without further notice to any products herein to improve reliability, function or design. ACTiSYS does not assume any liability arising out of the application or use of any product or circuit described herein. -
Page 6: Introduction
It features an integrated IR head and adapter body without external power supply. Small in size and light in weight makes it more convenient for traveling users. ACT-IR100M is compliant with the Infrared Data Association (IrDA compliant PCs running Windows 95/98/2000/ME/XP, Palm OS 3.2 or above and Windows CE 3.0 or above. It has an infrared data transmission rate of up to 115.2 kbps. -
Page 7: Act-Ir100Mp Led Behavior
The Wireless Connectivity Expert ACT-IR100MP LED BEHAVIOR Name Blink Slowly © Copyright 1999-2008 ACTiSYS Corp. Figure 2 : ACT-IR100MP Status Before Detecting IR Device IR Signal Detected IR Communicating Page 7 of 14 ACT-IR100M/IR100MP User’s Manual Meanings Mar 24, 2008... -
Page 8: Parts Check List
5.1. Your PC which uses passing through: • A Centronics parallel port. • A cable connecting your PC Centronics port and IR100M/IR100MP Centronics 36F port. • A printer which is within ACTiSYS IR100M/IR100MP compatibility list. • Proper printing software and proper printer driver on your PC. -
Page 9: Setup Procedure
ACT-IR100M/IR100MP The Wireless Connectivity Expert User’s Manual SETUP PROCEDURE Figure 3: Connection Diagram with Passing Thru Figure 4: Connection Diagram without Passing Thru © Copyright 1999-2008 ACTiSYS Corp. Page 9 of 14 Mar 24, 2008 Version 3.2.2.1... - Page 10 7. Add a new printer on Printers, set the Local Printer/LPT1 and choose proper printer driver (if you use pass through). For details, see Windows Printer Setting. step 8. Print by Windows application’s Print (pass through). The parallel LED on the top of IR100M will flash. If not, see Troubleshooting.
-
Page 11: Trouble Shooting
For help on general and miscellaneous problems you may be experiencing with your printing, refer to the following pages for possible solutions. Look up your problem and try the solution. Note: Please check your printer if it is on the ACT-IR100M/ACT-IR100MP compatibility list first. If not, contact ACTiSYS technical support. -
Page 12: Specifications
AC 120V 50/60Hz with AC Power adapter. 7.5V DC, 300mA (AC adapter for spec. of other Source countries also available) © Copyright 1999-2008 ACTiSYS Corp. ACT-100M/100MP Infrared radiation (peak wavelength: 850 to 1050 nm) 9.6, 19.2, 38.4, 57.6, 115.2 kbps None 8 bit 1 bit Centronics 36F/36M Cable to Parallel Printer. -
Page 13: Warranty Infomation
THE FOLLOWING WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. ACTiSYS Corporation warrants to the first end-user purchaser, for a period of 1 year from the date of purchase, that this wireless interface The PRODUCT will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof at no charge to the purchaser for parts or for labor. -
Page 14: 10. Contact Information
ACT-IR100M/IR100MP The Wireless Connectivity Expert User’s Manual 10. CONTACT INFORMATION ACTiSYS Corporation 921 Corporate Way Fremont, CA 94539, USA TEL:+1-510-490-8024, FAX:+1-510-623-7268 irda-info@actisys.com E-Mail: © Copyright 1999-2008 ACTiSYS Corp. Page 14 of 14 Mar 24, 2008 Version 3.2.2.1...
