ACT-IR100SL and
ACT-IR100SL-M
User's Manual
(IrDA Intelligent RS232 Adapters)
© Copyright 2000-2002 ACTiSYS Corporation,
All Rights Reserved
May 27, 2002 Ver. 1.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACT IR100SLM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ACTiSYS ACT IR100SLM

  • Page 1 48511 Warm Springs Blvd., Suite 206, Fremont CA 94539 Tel: (510) 490-8024 Fax: (510) 623-7268 Website: http://www.actisys.com/ E-mail: irda-info@actisys.com ACT-IR100SL and ACT-IR100SL-M User’s Manual (IrDA Intelligent RS232 Adapters) © Copyright 2000-2002 ACTiSYS Corporation, All Rights Reserved May 27, 2002 Ver. 1.20...
  • Page 2 FCC & VCCI Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING-FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user authority to operate this equipment NOTE: This equipment has been tested and found to comply with the limits for Class B digital device,...
  • Page 3: Table Of Contents

    On Line Change Host Speed and Hardware Flow Control/Connection Control RS-232C DTE DB-9P Connector 5. How to Connect IR100S-L/LM with host Device... 15 OTHER ACTiSYS IrDA PRODUCTS ... 17 LIMITED WARRANTY... 18 ACT-IR100SL and IR100SL-M User’s Manual TABLE OF CONTENTS ...
  • Page 4: Precautions

    !"Never touch the pins of computer connection terminal. The internal circuits can be damaged by a static electricity discharge. If this device requires any servicing, use only an ACTiSYS service dealer, an ACTiSYS approved service facility, or an ACTiSYS repair service.
  • Page 5: Featarus

    ACT-IR100SL and IR100SL-M User’s Manual 1. Features Support IrDA standard including: - IrLAP - IrLMP - TinyTP - IrCOMM - IrOBEX transport Other standards: - IrLPT IrDA baud rate supported: - 9.6kbps - 19.2kbps - 38.4kbps - 57.6kbps - 115.2kbps IrDA Primary/Secondary Mode supported: - IR100SL : Secondary Mode only - IR100SL-M : Both Primary and Secondary Mode supported, and mode automatically...
  • Page 6 ACT-IR100SL and IR100SL-M User’s Manual Host interface baud rate supported: - 1.2kbps - 2.4kbps - 4.8kbps - 9.6kbps - 19.2kbps - 38.4kbps - 57.6kbps - 115.2kbps - 5 - Version 1.20 May 27, 2002...
  • Page 7: Overview

    2. Overview The ACT-IR100S-L/LM is a IrDA-Ready intelligent adapter. This enables the host system with IrDA communication capabilities. The host system may be a serial printer, a modem, an industrial controller, a data collector, a medical instrument, or any other device, that may benefit from being IrDA enabled.
  • Page 8: Applications

    3. Applications 3.1 Embedded IrDA protocol stack The mandatory IrDA protocol layers, IrLAP (comply with TEST frame capability requirement) and IrLMP (including IAS) are handled by ACT-IR100S-L/LM, In addition, TinyTP, IrCOMM, IrLPT, IrOBEX transport are all included. The incoming/outgoing IrDA user data payload are buffered and then transferred to/from the host. The baud rates of IrDA traffic and host interface are independent of each other.
  • Page 9 ACT-IR100SL and IR100SL-M User’s Manual HOST RS232 converter (75LV737A) ACT-IR100S-L UART1 Buffers IrCOMM 9-wire OBEX Transport ACT-IR8200IC-L TinyTP TinyTP IrLPT or IrCOMM 3-wire raw IrLMP IrLAP UART0 IrPHY encoder-decoder (ACT-IR220VACF) IrDA Transceiver - 8 - Version 1.20 May 27, 2002...
  • Page 10: Operation Setting, Eeprom, And Other Optional Hardware

    4. Operation Setting, EEPROM, and other optional hardware 4.1 Serial EEPROM There are some special functions if the external serial EEPROM installed. The optional serial EEPROM allow users to set ”Host Speed” and “Hardware Flow Control and Connection Control”. The system initial sequence are shown below: Note: The serial EEPROM setting can override jumper settings.
  • Page 11: Baud Rate Setting

    4.2 Baud Rate Setting Jumpers SEL0-2 and serial EPROM settings are used to set the host interface RXD and TXD data rate. Note that this is independent of the IrDA connection data rate. Data format is always 8 data bits, no parity, and 1 stop bit. Note that this is compatible with end-to-end data format using 7 data bits, parity, and 1 stop bit.
  • Page 12: Ignore Dsr

    4.3 Ignore DSR SEL3 open(SEL3=1) means ignore the physical DSR input, pretend that DSR is on. This logical DSR is always used for connection control. The physical DTR is used for connection indication. SEL3 has no effect on DTR. When SEL3 close(SEL3=0), DSR is used for connection control. Active DSR permits IrDA connection. Inactive DSR forbids new connection and terminates existing connection.
  • Page 13: Eeprom Function Disable

    4.5 EEPROM Function Disable Jumper SEL7 is use to enable or disable EEPROM function. If this function disable, IR100S-L/LM will use SEL0~SEL4 setting only. If this function enable, IR100S-L/LM will use EEPROM setting and jumpers SEL0~SEL4 are ignored. Jumper Function SEL7 Disable Enable...
  • Page 14: On Line Change Host Speed And Hardware Flow Control/Connection Control

    ACT-IR100SL and IR100SL-M User’s Manual 4.6 On Line Change Host Speed and Hardware Flow Control/Connection Control The ACT-IR100S-L/LM allowed user to change Host Speed or Hardware Flow Control/Connection Control in run time. IRSET can change setting and write new value into the EEPROM via IR. COMSET can change setting and write new value into the EEPROM via COM port.
  • Page 15: Front View

    4.7 RS-232C DTE DB-9P Connector Pin No. Name ACT-IR100SL and IR100SL-M User’s Manual Descriptions Data Carrier Detect Receiver Data Transmitter Data Data Terminal Ready Signal Ground Data Set Ready Request to Send Clear to Send Ring Indicator - 14 - Front View Version 1.20 May 27, 2002...
  • Page 16: How To Connect Ir100S-L/Lm With Host Device

    5. How to Connect IR100S-L/LM with host Device IR100S-L/LM uses a standard RS232 DTE port to connect with the host. If the host device is a Modem like device and has a RS232 DCE port, then use a "straight cable". That is, connect the signals with the same name from one side to the other.
  • Page 17 If the host device is a PC like device and has a RS232 DTE port too, then you need to use a "Null Modem" connection between the two. That is, in/out signal pairs need to be crossed. ACT-IR100SL and IR100SL-M User’s Manual IR100S-L - 16 - Version 1.20...
  • Page 18: Other Actisys Irda Products

    OTHER ACTiSYS IrDA PRODUCTS I (ACT-1): IrDA Primary Station Protocol Stack !"IrLAP, IrLMP, IAS and optional Tiny TP, IrCOMM, IrMC, IrTran-P, etc.. !"For PDA, digital camera, handheld data terminal, palmtop computer, smart phone. !"Very tight code, modular design, easy porting and API interface, well supported.
  • Page 19: Limited Warranty

    HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. LIMITED WARRANTY ACTiSYS Corporation warrants to the first consumer purchaser, for a period of 1 year from the date of purchase, that this wireless interface (The Product? Will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof at no charge to the purchaser for parts or for labor.
  • Page 20 Corporation 48511 Warm Springs Blvd, Suite 206, Fremont, CA 94539, USA Tel:+1-510-490-8024 Fax:+1-510-623-7268 Internet: irda-info@actisys.com Web Site: http://www.actisys.com ACT-IR100SL and IR100SL-M User’s Manual Copyright 1995-2001 ACTiSYS Corp. - 19 - Version 1.20 May 27, 2002...
