The Wireless Connectivity Expert
921 Corporate Way, Fremont CA 94539 USA
Tel: +1-510-490-8024
Fax: +1-510-623-7268
Website:
http://www.actisys.com/
E-mail:
irda-info@actisys.com
ACT-IR100S-L & ACT-IR100SL-M
TM
(IrReady
Intelligent Adapter)
User's Manual
April 22, 2008
Ver. 1.2.0.1
© Copyright 2000-2008 ACTiSYS Corporation
All Rights Reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACTiSYS IR100SL
Summary of Contents for ACTiSYS IR100SL
- Page 1 The Wireless Connectivity Expert 921 Corporate Way, Fremont CA 94539 USA Tel: +1-510-490-8024 Fax: +1-510-623-7268 Website: http://www.actisys.com/ E-mail: irda-info@actisys.com ACT-IR100S-L & ACT-IR100SL-M (IrReady Intelligent Adapter) User’s Manual April 22, 2008 Ver. 1.2.0.1 © Copyright 2000-2008 ACTiSYS Corporation All Rights Reserved...
- Page 2 Please retain this information. Model Number Date of Purchase All indicated copyrights and trademarks in the following pages are copyrights and trademarks of their Respective corporations. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ACT-IR100S-L and IR100SL-M Serial Number Place of Purchase Page 2 of 20 User’s Manual...
-
Page 3: Table Of Contents
On Line Change Host Speed and Hardware Flow Control/Connection Control... 14 RS-232C DTE DB-9P Connector... 15 5.HOW TO CONNECT IR100S-L/LM WITH HOST DEVICE ... 16 6.OTHER ACTiSYS IrDA PRODUCTS... 18 7.WARRANTY ... 19 8.CONTACT INFORMATION ... 20 © Copyright 2000-2008 ACTiSYS Corp. -
Page 4: Precautions
Never touch the pins of computer connection terminal. The internal circuits can be damaged by a static electricity discharge. If this device requires any servicing, use only an ACTiSYS service dealer, an ACTiSYS approved service facility, or an ACTiSYS repair service. -
Page 5: Revision History
ACTiSYS reserves the right to make changes without further notice to any products herein to improve reliability, function or design. ACTiSYS does not assume any liability arising out of the application or use of any product or circuit described herein. -
Page 6: Features
- 115.2kbps Primary/Secondary Mode supported: - IR100S-L : Secondary Mode only - IR100SL-M : Both Primary and Secondary Mode supported, and mode automatically switched upon IrDA protocol negotiation with the other device. Host Interface: - Full-duplex asynchronous serial (TXD, RXD) (Or simplex TXD only and software flow control with RXD.) -
Page 7: Overview
Figure 2.1 System Block Diagram 75LV4737 /TXD /RXD RS232C /RTS1 /CTS1 /DSR1 /DTR1 /CD1 /RI1 © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information intelligent adapter. This enables the host system with IrDA ACT-IR100S-L IR8200IC /TXD1 /RXD0 /RXD1 /TXD0 /RTS0 /RTS1... -
Page 8: Applications
The IrPHY specification allows two kinds of modulations: 3/16 of a bit duration pulse, or minimum pulse duration of 1.63 us, we use minimum pulse duration of 1.63 us to modulation bit data. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ®... - Page 9 Wireless Connectivity Expert ACT-IR100S-L ACT-IR8200IC-L © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information HOST RS232 converter (75LV737A) UART1 Buffers IrCOMM 9-wire TinyTP IrLPT or IrCOMM 3-wire raw IrLMP IrLAP UART0 IrPHY encoder-decoder (ACT-IR220VACF) IrDA Transceiver Page 9 of 20 ACT-IR100S-L and IR100SL-M User’s Manual...
-
Page 10: Operation Setting, Eeprom & Other Optional Hardware
The optional serial EEPROM allow users to set ”Host Speed” and “Hardware Flow Control and Connection Control”. The system initial sequence are shown below: Note: The serial EEPROM setting can override jumper settings. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information System Power ON. -
Page 11: Baud Rate Setting
The Host Interface can operate on eight different baud rates from 1.2kbps to 115.2kbps. PCB bottom view Baud Rate SEL2 1.2kbps 2.4kbps 4.8kbps 9.6kbps 19.2kbps 38.4kbps 57.6kbps 115.2kbps © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information SEL7 SEL6 SEL5 SEL4 Jumpers SEL1 SEL0 Page 11 of 20 ACT-IR100S-L and IR100SL-M User’s Manual... -
Page 12: Ignore Dsr
When SEL4 close, CTS is used for flow control of TXD. Active CTS permits TXD. Inactive CTS forbids TXD. Jumper Ignore CTS SEL4 © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information Descriptions Ignore DSR input. DSR is used for IR connection control. -
Page 13: Eeprom Function Disable
4. In IrCOMM 9-wire connection IR100S-L always response DCE line status if line state is changed or response Poll for Line Settings via IrLMP control channel. Independent of the IR flow control, HOST data flow control and baudrate is not obey IrCOMM control parameters. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information Descriptions Disable EEPROM function... -
Page 14: On Line Change Host Speed And Hardware Flow Control/Connection Control
Control in run time. IRSET can change setting and write new value into the EEPROM via IR. COMSET can change setting and write new value into the EEPROM via COM port. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ACT-IR100S-L and IR100SL-M Page 14 of 20 User’s Manual... -
Page 15: Rs-232C Dte Db-9P Connector
Wireless Connectivity Expert 4.7 RS-232C DTE DB-9P Connector Pin No. Name © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information Descriptions Data Carrier Detect Receiver Data Transmitter Data Data Terminal Ready Signal Ground Data Set Ready Request to Send Clear to Send... -
Page 16: How To Connect Ir100S-L/Lm With Host Device
IR100S-L/LM uses a standard RS232 DTE port to connect with the host. If the host device is a Modem like device and has a RS232 DCE port, then use a "straight cable". That is, connect the signals with the same name from one side to the other. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ACT-IR100S-L and IR100SL-M... - Page 17 If the host device is a PC like device and has a RS232 DTE port too, then you need to use a "Null Modem" connection between the two. That is, in/out signal pairs need to be crossed. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information...
-
Page 18: Other Actisys Irda Products
For printer, pager, docking station, medical device, cell phone, storage devices. Very tight code, modular design, easy porting and API interface, well supported. Small code size (4 - 20K bytes), well tested and inter-operate with all IrDA devices. © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ®... -
Page 19: Warranty
Wireless Connectivity Expert WARRANTY ACTiSYS Corporation warrants to the first consumer purchaser, for a period of 1 year from the date of purchase, that this wireless interface (The Product? Will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof at no charge to the purchaser for parts or for labor. -
Page 20: Contact Information
Wireless Connectivity Expert CONTACT INFORMATION ACTiSYS Corporation 921 Corporate Way, Fremont, CA 94539, USA TEL:+1-510-490-8024, FAX:+1-510-623-7268 E-Mail: irda-info@actisys.com Web: http://www.actisys.com © Copyright 2000-2008 ACTiSYS Corp. ACTiSYS Confidential Information ACT-IR100S-L and IR100SL-M Page 20 of 20 User’s Manual Apr. 22, 2008 Version 1.2.0.1...
