PCI-DIO96H User's Guide
Pin Signal name
100 GND
99 +5V
98 THIRDPORTC Bit 0
97 THIRDPORTC Bit 1
96 THIRDPORTC Bit 2
95 THIRDPORTC Bit 3
94 THIRDPORTC Bit 4
93 THIRDPORTC Bit 5
92 THIRDPORTC Bit 6
91 THIRDPORTC Bit 7
90 THIRDPORTB Bit 0
89 THIRDPORTB Bit 1
88 THIRDPORTB Bit 2
87 THIRDPORTB Bit 3
86 THIRDPORTB Bit 4
85 THIRDPORTB Bit 5
84 THIRDPORTB Bit 6
83 THIRDPORTB Bit 7
82 THIRDPORTA Bit 0
81 THIRDPORTA Bit 1
80 THIRDPORTA Bit 2
78 THIRDPORTA Bit 3
78 THIRDPORTA Bit 4
77 THIRDPORTA Bit 5
76 THIRDPORTA Bit 6
75 THIRDPORTA Bit 7
74 FOURTHPORTC Bit 0
73 FOURTHPORTC Bit 1
72 FOURTHPORTC Bit 2
71 FOURTHPORTC Bit 3
70 FOURTHPORTC Bit 4
69 FOURTHPORTC Bit 5
68 FOURTHPORTC Bit 6
67 FOURTHPORTC Bit 7
66 FOURTHPORTB Bit 0
65 FOURTHPORTB Bit 1
64 FOURTHPORTB Bit 2
63 FOURTHPORTB Bit 3
62 FOURTHPORTB Bit 4
61 FOURTHPORTB Bit 5
60 FOURTHPORTB Bit 6
59 FOURTHPORTB Bit 7
58 FOURTHPORTA Bit 0
57 FOURTHPORTA Bit 1
56 FOURTHPORTA Bit 2
55 FOURTHPORTA Bit 3
54 FOURTHPORTA Bit 4
53 FOURTHPORTA Bit 5
52 FOURTHPORTA Bit 6
51 FOURTHPORTA Bit 7
Table 6. Main connector pin out
Pin
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
19
Signal name
GND
+5V
FIRSTPORTC Bit 0
FIRSTPORTC Bit 1
FIRSTPORTC Bit 2
FIRSTPORTC Bit 3
FIRSTPORTC Bit 4
FIRSTPORTC Bit 5
FIRSTPORTC Bit 6
FIRSTPORTC Bit 7
FIRSTPORTB Bit 0
FIRSTPORTB Bit 1
FIRSTPORTB Bit 2
FIRSTPORTB Bit 3
FIRSTPORTB Bit 4
FIRSTPORTB Bit 5
FIRSTPORTB Bit 6
FIRSTPORTB Bit 7
FIRSTPORTA Bit 0
FIRSTPORTA Bit 1
FIRSTPORTA Bit 2
FIRSTPORTA Bit 3
FIRSTPORTA Bit 4
FIRSTPORTA Bit 5
FIRSTPORTA Bit 6
FIRSTPORTA Bit 7
SECONDPORTC Bit 0
SECONDPORTC Bit 1
SECONDPORTC Bit 2
SECONDPORTC Bit 3
SECONDPORTC Bit 4
SECONDPORTC Bit 5
SECONDPORTC Bit 6
SECONDPORTC Bit 7
SECONDPORTB Bit 0
SECONDPORTB Bit 1
SECONDPORTB Bit 2
SECONDPORTB Bit 3
SECONDPORTB Bit 4
SECONDPORTB Bit 5
SECONDPORTB Bit 6
SECONDPORTB Bit 7
SECONDPORTA Bit 0
SECONDPORTA Bit 1
SECONDPORTA Bit 2
SECONDPORTA Bit 3
SECONDPORTA Bit 4
SECONDPORTA Bit 5
SECONDPORTA Bit 6
SECONDPORTA Bit 7
