Specifications
Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.

Digital input / output

Digital type
Output
Input
Configuration
Number of I/O
Output high
Output low
Input high
Input low
Power-up / reset state
Pull-up/pull-down resistors

Power Consumption

+5V Operating

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions
Table 1. Digital I/O specifications
8255 emulation, Mode 0
74S244
74LS373
8 banks of 8, 8 banks of 4, programmable by bank as input or output
96
2.4 volts min @ -15 mA
0.5 volts max @ 64 mA
2.0 volts min, 7 volts absolute max
0.8 volts max, -0.5 volts absolute min
Input mode (high impedance)
SIP resistor locations provided for pull-up or pull-down configuration.
Table 2. Power consumption specifications
2.1 A typical, 3.4 A max
Table 3. Environmental specifications
0 to 50 °C
-20 to 70 °C
0 to 90% non-condensing
Table 4. Mechanical specifications
292.1 mm (L) x 106.6 mm (H) x 14.5 mm (W)
