ACT-IR110SD
Supports mandatory IrDA
Supports upper layers TinyTP
Supports host baud rate from 1.2 kbps to 115.2 kbps, which is changeable by utility;
IrDA baud rate from 9.6 kbps to 115.2 kbps, which is flexible setting by IrDA devices.
Supports both IrDA Primary and Secondary mode, changeable via Comset_IR100SD.exe.
Battery operated intelligent adaptor.
No driver is needed.
IR frame and Host buffer are 2048 bytes separately.
Supply voltage: 6.0 V to 12 V.
Power consumption: 1.650 mA on standby mode,
60 mA on active mode.
Supports 3 wires host interface (Tx, Rx and GND).
Interface to Host:
- Full duplex asynchronous serial (TXD, RXD)
- Hardware flow control (RTS, CTS)
- Optional line status for link control (DTR, DSR)
All trademarks, logos, organization & company names and product model names are owned by the respective
organizations or companies.
The only IrDA
adapter supplier that has test tools to help your system to be IrDA
®
®
®
D
A
–
R
D
A
–
R
, an IrDA
, an IrDA
®
layer: IrPHY
TM
, IrCOMM
S
2
3
2
A
D
S
2
3
2
A
D
®
®
Intelligent Embedded RS232 Adapter
Intelligent Embedded RS232 Adapter
TM
TM
, IrLAP
, IrLMP
TM
TM
, IrLPT
, and OBEX
A
P
T
E
R
A
P
T
E
R
TM
TM
and IAS
.
TM
transport.
compliant !
®
