Telephone layout
Cordless 1-line CTM-A2415 Base
1
MESSAGE WAITING LED
2
Wall mount clip
3
Faceplate slot with Speed dial keys
(Programmable)
SPD5
SPD6
SPD7
SPD8
REPLACE BATTERY LED
4
VOL + | VOL - (VOLUME +/-)
5
SPEAKER
6
CHARGE LED
FIND HS (FIND HANDSET)
7
8
Grooves for Mounting bracket
9
Voicemail voltage detection
10
Battery compartment with cover
11
Grooves for Base stand
12
Telephone jack
13
Base battery ON pinhole
EN - 7
