VTech Analog Contemporary Series Master User Manual page 10

Installation option - converting
from desktop to wall mount position
To mount the telephone base on the wall
1. Unmount the base stand. Put the cordless
handset aside. On the telephone base, press
the wall mount clip upward and rotate a half
turn (180°). Slide back the clip.
• It locks into place with the protruding edge
pointing towards the upper edge of the
telephone base. This protruding edge
holds the cordless handset when the phone
is mounted on the wall.
2. Turn the telephone base over with the
bottom side facing up. Press the tabs of the
mounting bracket as the direction indicated
into the grooves on the telephone base until
they lock securely.
3. Mount the telephone base on the wall
by positioning the eyelets on the telephone
base and the mounting bracket against the
mounting studs. Then slide the telephone
base down on both mounting studs until it
locks into place.
4. Replace the handset on the telephone
base cradle.
Mounting
bracket
Eyelets
EN - 10
Protruding
edge
