connector (SFF-8644) on one end (to connect to the HBA) and the appropriate connector to attach to the enclosure
that contains SAS devices or SATA devices on the other end.
7. Make sure the system provides the required airflow for the controller. Airflow must be at least 200 linear feet
per minute (LFM) at 55 °C inlet temperature to avoid operating the Broadcom SAS 3216 processor above the
maximum junction temperature.
8. Replace the cover and reconnect any cords and cables, and power up the system. Replace the chassis's cover,
reconnect any power cords, and reconnect any network cables. Turn on the power.
8

Technical Support

For assistance installing, configuring, or running the Broadcom 12Gb/s SAS HBA, contact Technical Support at
http://www.avagotech.com/support/.
Broadcom Ltd.
- 9 -
