EN
5.0
CONNECTION AND OPERATION
1) Connect the HDMI input source and output devices into the HDMI Splitter. (HDMI cables are optional)
*please refer to the connection diagram section.
2) Insert the DC side of 5v power supply into it and then connect the AC side of the power supply into
the wall outlet.
3) Turn on the power.
Attention: Insert / Extract cable gently.
5.1
CONNECTION DIAGRAM
INPUT
HDMI DVD
10
HDMI CABLE
MINI HDMI SPLITTER 1×4
HDMI CABLE
HDMI CABLE
OUTPUT
HDMI TV
HDMI TV
