HDMI EXTENDER SPLITTER
OVER CAT6 WITH IR

CONNECTION AND OPERATION

Network cable
Follows the standard EIA-568B:
1- Orange/white
2- Orange
3- Green/white
4- Blue
CONNECTION
Ingresso
alimentazione
(DC5V)
Reset IR blaster
button extension
port
HDMI Signal
input link LED
HDMI EXTENDER TX
(Sender)
IDATA EXTIP-383RV4
HDMI EXTENDER
RJ45 output
5- Blue/white
6- Green
7- Brown/white
8- Brown
DVD
RX ( R eceiver)
T V
Power input
(DC5V)
Cable
T V
T V T V
WWW.TECHLY.COM
9
