MINI DISPLAYPORT V.1.2
TO HDMI ADAPTER
4.0 PANEL DESCRIPTIONS
5.0 CONNECTION AND OPERATION
1) Connect the Mini DisplayPort male to Mini DisplayPort source device.
2) Connect the HDMI female to display by HDMI M/M cable.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
HDTV
MINI DISPLAYPORT1.2 TO HDMI CONVERTER
NOTEBOOK
WWW.TECHLY.COM
EN - 5
