DIGITAL-LOGIC MICROSPACE MSMV104+ Technical User's Manual page 27

DIGITAL-LOGIC AG
8.3 Low resolution modes
Low Resolution Modes
Mode # (Hex) Type
40 Gr
41 Gr
42 Gr
43 Gr
44 Gr
45 Gr
46 Gr
47 Gr
48 Gr
49 Gr
8.4 Extended modes
640x480 Extended Modes
Mode VESA Type
# Mode #
(Hex) (Hex)
50 101 Gr
52 111 Gr
53 112 Gr
54 Gr
800x600 Extended Modes
Mode VESA Type
# Mode #
(Hex) (Hex)
6A 6A Gr
55 103 Gr
57 114 Gr
58 115 Gr
59 Gr
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Colors Resolutions Vsync (Hz) Video Memory
256 320x200 70
64K 320x200 70
256 320x240 75, 60
64K 320x240 75, 60
256 400x300 75, 60
64K 400x300 75, 60
256 512x384 75
64K 512x384 75
256 640x400 70
64K 640x400 70
Colors Alpha Font
Format
256 80x30 8x16
64K 80x30 8x16
(16-bit)
16M 80x30 8x16
(24-bit)
16M 80x30 8x16
(32-bit)
Colors Alpha Font
Format
16 100x75 8x8
256 100x75 8x8
64K 100X75 8X8
(16-bit)
16M 100X75 8X8
(16-bit)
16M 100X75 8X8
(24-bit)
26
MSMV104+ manual V1.0
1MB
1MB
1MB
1MB
1MB
1MB
1MB
1MB
1MB
1MB
VCLK Hsync Vsync
(MHz) +/- +/-
(KHz) (Hz)
25.0 31.5 60
31.5 37.5 75
36.0 43.3 85
25.0 31.5 60
31.5 37.5 75
36.0 43.3 85
25.0 31.5 60
31.5 37.5 75
36.0 43.3 85
25.0 31.5 60
31.5 37.5 75
36.0 43.3 85
VCLK Hsync Vsync
(MHz) +/- +/-
(KHz) (Hz)
40.0 37.9 60
40.0 37.9 60
49.5 46.9 75
56.25 53.7 85
40.0 37.9 60
49.5 46.9 75
56.25 53.7 85
40.0 37.9 60
49.5 46.9 75
56.25 53.7 85
40.0 37.9 60
49.5 46.9 75
56.25 53.7 85
Buffer Start
A0000
A0000
A0000
A0000
A0000
A0000
A0000
A0000
A0000
A0000
Video Buffer
Memory Start
512 KB A0000
1MB A0000
1MB A0000
2MB A0000
Video Buffer
Memory Start
256KB A0000
512KB A0000
1MB A0000
2MB A0000
2MB A0000
