ZV-Port connector signals

The following table shows the signals, that are present on the ZV-Port connector J15
J15 Pin Signal
1 Z0
3 Z2
5 Z4
7 Z6
9 Z8
11 Z10
13 Z12
15 Z14
17 NC
19 Href
21 Blank
23 DDC SCL
25 No connection
27 VCC
29 No connection
4.6

CRT Connector signals

P1 Pin Signal
1 RED
3 BLUE
5 AGND
7 AGND
9 NC
11 NC
13 HSYNC
15 DDC_SCL
4.7

S-Video connector signals

J29 Pin Signal
1 Y
