2.3

Multimedia features

The Lynx3DM motion compensation hardware allows full- frame playback of DVD content in software. Making use of
its independent bus-master interface and its ability to alpha blend sub-picture data, the Lynx3DM offloads the CPU
and eliminates the need for a dedicated decoder.
The MSMV104+ graphic controller integrates a TV encoder with NTSC/PAL support and provide
-
graphic/video display on TV without the need of any external logic
The MSMV104+ GPU has a built-in MPEG2 hardware motion compensation decoder so as to enable
-
easy DVD playback and to offload the main CPU.
One primary and up to two secondary displays are supported, included dual digital display capability
-
under Win95, Win98, WinMe, WinNT, WinCE, Win2000 and Linux.
The MSMV104+ is also fitted with a Zoom Video Port to support input from camera or TV-tuner and
-
allow easy monitoring, processing and recording of data.
3 S
OFTWARE
The software can be found in the MICROSPACE Application CD
CD:\drivers\vga\lynx-3dm_smi721\
dos
lynx3DM-nt4-4.zip
lynx3DM-win98-4.zip
lynx3DM-winme-4.zip
lynx3DM-win2k-4.zip
CD:\products\msm\peripheral
pc104+\msmv104\manual
Msmv104plus.pdf
CD:\ products\msm\peripheral
pc104+\msmv104\tools\
CP42a.zip
CD:\ products\msm\peripheral
pc104+\msmv104\tools\
CP42a.zip
CD:\ lcd\ vgabios\ lynx-3dm_smi721\ SMI721-
crt.zip
SMI721-crt.zip
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Drivers for
DOS
Windows NT4.0
Windows 95
Windows Me
Windows 2000
Manual
This file
Control panel
Control panel for SMI721
Control panel
Control panel for SMI721
Bios
"CRT Bios" for SMI721
9
