DIGITAL-LOGIC AG
7.3
Accessing chip functionality under Windows
After the control panel be installed, you can access the extended display properties by clicking on the
SMI icon to be found at the right bottom of your diplay
Figure 8.3a: Location of the SMI icon for direct access to the extended display properties
7.4
Control panel functionalities
The control panel enables different standard features, such as to change the display resolution, color
depth... But it also fit with some additional nice features, which make possible to choose the display
output, the display rotation or to enter stretch mode, which can enable for LCD for example a 640x480
resolution to be extended to a full 800x600 display.
The following sections show the different features together with a small summary of the different display
modes which can be set.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Click on the SMI icon
21
MSMV104+ manual V1.0
