Getting Started

Connecting the Projector

DVD player, Set-top Box
HDTV receiver
USB
RS232
# Description
1 Power cord
2 VGA cable
3 Composite video cable
4 USB cable
5 VGA to component/HDTV adapter
Note: To ensure the projector works well with your computer,
please make sure the timing of the display mode is compatible
with the projector.
VGA, DVI
R B G
D-Sub
DVI-D
D-Sub
R B G
HDTV adapter
D-Sub
DVI-D
D-Sub
#
6
7
8
9
Video Output
Y
Y
S-Video Output
Description
S-Video cable
Audio cable
DVI cable
HDMI cable (P5260E/P5260EP series)
7
