- Page 1 USER’S MANUAL Thermal Printer BT-UC056Ⅲ Shandong New Beiyang Information Technology Co., Ltd. ...
- Page 2 Information in this document is subject to change without notice. SHANDONG NEW BEIYANG INFORMATION TECHNOLOGY CO., LTD. (hereinafter referred to as “SNBC”) reserves the right to improve product as new technology, components, software, and firmware become available. If users need further data about this product or have any doubt about safety issues that might arise from using it, please feel free to contact your dealer.
- Page 3 BT-UC056Ⅲ User’s Manual General Safety Information Pay attention to the following instructions before using the printer. 1. Safety Instructions Caution: The print head is calorific and its temperature is high when printing or just after operation, so please don’t touch it or its peripherals for safety purpose; Warning: The print head is an ESD-sensitive device.
-
Page 4: Table Of Contents
BT-UC056Ⅲ User’s Manual CONTENTS 1 Introduction..............................1 1.1 Outline..............................1 1.2 Main Features ............................. 1 2 Main Specifications............................ 2 2.1 Technical Specifications ........................2 2.2 Media Specifications..........................2 3 Physical Appearance and Dimension ......................3 3.1 Appearance ............................3 3.2 Printer Unit Description ........................ -
Page 5: Introduction
BT-UC056Ⅲ User’s Manual 1 Introduction 1.1 Outline BT-UC056 printer is a kind of high-performance thermal printer which supports liner-free label. It has following features: high-speed, low-noise, reliable performance and easy maintenance, etc, and it can be widely used in various fields requiring real-time label or receipt printing, such as electronic scale and so on. 1.2 Main Features Easy operation, low maintenance Durable metal frame structure... -
Page 6: Main Specifications
BT-UC056Ⅲ User’s Manual 2 Main Specifications 2.1 Technical Specifications Item Specifications Model BT-UC056Ⅲ Print mode Direct thermal line Print speed 75mm/s Print width 56mm Paper width 60mm (Max.) Resolution 203DPI Paper type Thermal paper and liner-free label paper Paper out method Tear off Print head temperature detection Thermistor... -
Page 7: Physical Appearance And Dimension
BT-UC056Ⅲ User’s Manual 3 Physical Appearance and Dimension 3.1 Appearance 1-Power LED 2-Error LED 3- Button 4-Top cover module 5-Tear-off bar 6-Paper exit 7-Top cover open spanner 8-Paper roll release axis 9-Circuit board module 10-Button circuit board 11-Print head micro switch 12-Tension spring for top cover opening 13-Transmission gear 14-Step motor 15-Serial interface socket... -
Page 8: Printer Unit Description
BT-UC056Ⅲ User’s Manual 3.2 Printer Unit Description Paper End Sensor (18): Paper presence/absence detection Paper jam Sensor (19): Paper jam detection Key Function (3): Continuous paper feed mode In standby mode, printer feeds paper after pressing this button; Press this button and turn on the printer, the printer will perform paper calibration. If occurs paper feeding or calibration error, press this button to clear the errors. -
Page 9: Led And Buzzer Description
BT-UC056Ⅲ User’s Manual 3.3 LED and Buzzer Description Error messages displayed by alarm LED and buzzer are described as below. Status LED Buzzer Problem Solution or Reason Self- recover when print head Print head cool down. overheated Self-recover when voltage back Voltage to normal. -
Page 10: Printer Physical Dimension
BT-UC056Ⅲ User’s Manual 3.4 Printer Physical Dimension Printer Physical Dimension 6 ... -
Page 11: Printer Operation
BT-UC056Ⅲ User’s Manual 4 Printer Operation 4.1 Paper Loading Pull paper roll guide out of paper roll supply reel as displayed in the figure below. Attention: Hold fast the bottom of paper roll guide. Rotate the paper roll guide to horizontal condition as shown in the figure below. Load the proper paper roll to the paper roll supply reel. - Page 12 BT-UC056Ⅲ User’s Manual Attention: Paper roll should be pushed to the end of paper roll supply reel. Paper roll rotates in the direction as shown in the above figure. Pay attention to its direction while loading the paper roll. Rotate the paper roll guide to vertical status as shown in the figure below.
- Page 13 BT-UC056Ⅲ User’s Manual Lift up the top cover as shown in the figure below. Lead the liner-free label paper through the paper path from the side. 9 ...
- Page 14 BT-UC056Ⅲ User’s Manual Attention: Paper will distort when feeds it, thus be careful not to tear off the paper and make sure the front end of paper pass the platen roller. Press down the print head as shown in the figure below. Attention: Hold the middle inner part of top cover while pressing down the print head to avoid deformation of top cover rotation shaft and affecting print output.
-
Page 15: Paper Calibration
BT-UC056Ⅲ User’s Manual Caution: Make sure the paper type setup before loading. Printer default paper type is liner-free paper with mark at its back (see command set). Label heat sensitive side should face print head. Label width could not wider than paper path. Label should close to sensor with no skew. -
Page 16: Routine Maintenance
BT-UC056Ⅲ User’s Manual 5 Routine Maintenance 5.1 Cleaning the Print Head When one or more of the following cases occur, clean the print head: Printout is not clear. One of the printed columns is not clear. Paper feeds and retracts with big noise. Follow the steps given below to clean the print head. -
Page 17: Troubleshooting
BT-UC056Ⅲ User’s Manual 6 Troubleshooting Refer to this chapter for solution when a problem occurs. If the problem still cannot be solved, please contact your local dealer or SNBC for assistance. 6.1 LED and Buzzer Problems Reason Solution Paper end Reload new paper roll.
