Appendix B: Accessories

Available Accessories
Part Number
0200-6117
9000-0161
R8024
4400-0002
4400-0036
4400-0037
4400-0038
2400-0116
Cuvettes
The following cuvettes have been tested with the instrument. All have an optical pathlength of
1 cm (10 mm) and standard external dimensions (12.5 cm x12.5 cm). Their fill volumes differ only
because of their different internal width and chamber height dimensions.
Standard and Semi-micro Cuvettes
Several brands available.
Internal Width
10 mm
4 mm
2 mm
Ultra-micro Cuvettes (Hellma)
When ordering, specify the Z-dimension to be 15 mm.
Hellma Cat. No.
105.201-QS
105.202-QS
105.210-QS
5065390 C
Description
SpectraTest ABS1 Absorbance Validation Test Plate
Cuvette Absorbance Validation Kit
SpectraPlate-Quartz UV-transparent Microplate
Power Cord (US, Canada, Japan, Mexico, India)
Power Cord, EC1 (Germany, France, Scandinavia, Italy, Korea)
Power Cord, EC2 (UK, Indonesia, Singapore, Malaysia)
Power Cord, AP1 (Australia, Hong Kong, China)
Dust Cover
Minimum Volume
~ 1.8 mL
~ 0.75 mL
~ 0.40 mL
Window Size
2.0 x 5.0 mm
a
2.0 x 2.5 mm
b
0.8 mm diameter
a. You must put a riser (0.8–1 mm) on cuvette bottom to match the
cuvette window to the beam. 2.0 x 2.5 mm 50 µL 70 µL 105.210-QSb
b. You must put a riser (0.8–1 mm) on cuvette bottom to match the
cuvette window to the beam. Gives good qualitative results (i.e.
spectral scans), but quantitative results are impractical because the
window is smaller than the beam.
Maximum Volume
4.0 mL
1.4 mL
0.7 mL
Chamber Volume
100 µL
50 µL
5 µL
B
Fill Volume
120 µL
70 µL
10 µL
