SpectraMax ABS and SpectraMax ABS Plus Microplate Spectrophotometers User Guide
Table 4: Error Codes 300-399: Hardware Errors
Error
Code
300
301
302
303
304
305
306
307
308
312
313
314
315
316
317
30
Error Message Notes
thermistor faulty Unable to read a reasonable thermistor value. Thermistor faulty or
disconnected, Main board problem, or ambient temperature out of range.
safe A temperature of over 50°C detected on one or more of the 4
temperature thermistors. Temperature will be shut off and remain off until a successful
limit exceeded completion of power-up reset.
low light Not enough light detected to make an accurate measurement. If doing a
cuvette read, the cuvette door may be open.
unable to cal Too much stray light detected on powerup, faulty or disconnected
dark current preamp boards.
signal level During a cuvette read, could be due to cuvette door being open.
saturation
reference level During a cuvette read, could be due to cuvette door being open.
saturation
plate air cal fail, Minimum signal/reference ratio not met during air calibration.
low light
cuv air ref fail
stray light Light leak in read chamber or cuvette door open. Could also be a faulty
pre-amp board
gain calibration Power-up calibration and check of signal path gain is out of tolerance.
failed Could be due to bad or disconnected pre-amp or excessive stray light.
reference gain Power-up check of the Reference amplifier's gain out of tolerance. Could
check fail be due to bad or disconnected pre-amp board or excessive stray light.
low lamp level
warning
can't find zero On power-up, grating motor could not find zero-order home position.
order
grating motor Grating motor did not move to where it was commanded to in a
driver faulty reasonable time.
monitor ADC
faulty
