BPBIO750
User's Manual
BPBIO750_manual_ENG_A_190522.indd 1
2019-06-24 오전 10:22:53

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPBIO750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for inbody BPBIO750

Summary of Contents for inbody BPBIO750

  • Page 1 BPBIO750 User’s Manual BPBIO750_manual_ENG_A_190522.indd 1 2019-06-24 오전 10:22:53...
  • Page 2 Reproduction, adaptation, or translation of this manual is prohibited without prior written consent from InBody Co., Ltd. under the copyright laws. This user manual may be printed incorrectly and subject to change without notice. InBody Co., Ltd. shall not be liable for any errors, incidental, or consequential damages that occurred by not complying with the content of the User’s Manual.
  • Page 3 Basic points A. Product Components The blood pressure monitor is a medical device for measuring blood pressure. B. User This blood pressure monitor must be used with medical professionals. C. Measuring person Adult / Children (more than 7 years old) with arm circumference 17cm ~42cm Caution Check that the patient has the following symptoms before using the blood pressure monitor.
  • Page 4 BPBIO750_manual_ENG_A_190522.indd 4 2019-06-24 오전 10:22:54...

  • Page 5: Table Of Contents

    BPBIO750 User’s Manual Contents I. Installing BPBIO750 A. Product Components B. Operating Environment C. Installation D. Loading and Reloading Printer Paper E. Replacing Cuff Cloth F. Setup G. Precautions for Maintenance II. Blood Pressure Test A. Precautions for Measurement B. Test Instructions C. Test Posture III.

  • Page 6: Installing Bpbio750

    I. Installing BPBIO750 A. Product Components BPBIO750 consists of the following components. Make sure all of the following components are present. check each component of the system for damage prior to installation. Basic Components BPBIO750 Power cable (AC 250V 10A 1.8m) 1 EA Two rolls of printing paper User’s Manual...

  • Page 7: Operating Environment

    Caution Do not carry the equipment by holding the cuff. • Keep packing material to repack the BPBIO750 at a later time. Dispose of trash according to local laws and • regulations. Refer to the figure below when transporting the BPBIO750.
  • Page 8 2. Place the equipment on a solid table that can withstand the weight of BPBIO750 (approx. 7.1kg). If dedicated desk for BPBIO750 is available, align the desk-fixing grooves on the bottom of BPBIO750 and the grooves on the desk and secure them with two fixing screws. Dedicated desk for BPBIO750 is sold separately. Desk fixing grooves Desk grooves Fixing screws Blood Pressure Guidelines ( A ge 18 and Over ) * Please consult with your doctor for accurate diagnosis.
  • Page 9 Theft protection cable is sold separately. Use the anti-theft cable whick is used for laptop etc. 5. Turn the BPBIO750 on by pressing the power switch located on the back of the device. Power switch 6. When BPBIO750 is turned on, the following screen is displayed and a self-test is automatically performed.

  • Page 10: Loading And Reloading Printer Paper

    • Remove all trash from previous printer paper rolls. • Note Two rolls of printer paper are provided with the BPBIO750. • If additional printer paper is necessary, the user must purchase it separately as a consumable item. • The user can purchase printer papers at www.inbodymall.com.

  • Page 11: Replacing Cuff Cloth

    E. Replacing Cuff Cover The cuff cover of the BPBIO750 should be replaced periodically for sanitary purposes. Follow the guide below to replace the cuff cover Print 1. Turn BPBIO750 off before replacing cuff cover. Remove the front cover of the BPBIO750 by pushing downward. Loosen the screw with a screwdriver. Screw Front Cover Front ring 2. Separate the cuff cover attached to the back of the arm insertion section by pulling it inward. 3. Pull the cuff cover on the front of the arm insert to remove it. BPBIO750_manual_ENG_A_190522.indd 9 2019-06-24 오전 10:23:00...
  • Page 12 Blood pressure results may be inaccurate if the seam does not face down. • Print 5. Attach the previously removed front ring on the BPBIO750, secure it with a screw and close the front cover. Screw Front Cover Front ring Note Two pieces of cuff cover are provided with the BPBIO750.

  • Page 13: Setup

    F. Setup Set up consists of time setting, sound setting, result sheet printing option, pressure unit setting, communications setting, result sheet printing items setting. 1. Setting Setup 1) If you press and hold the Start/Stop button and the Print button at the same time for more than 2 seconds in the Home screen, then ‘...
  • Page 14 2. Setup Example The following is an example of changing the output of the result sheet from automatic printing to manual printing. 1) At the Home screen, press and hold Start/Stop button and Print button at the same time for more than 2 seconds. The ‘...
  • Page 15 120 seconds YY / MM / DD Date output format MM / DD / YY DD / MM / YY mmHg Pressure unit InBody Communication Three vertical lines (relatively small Results sheet) Type of * F13-F18 function not available Results sheet...

  • Page 16: Precautions For Maintenance

    Make sure the power cord is located in a safe place to avoid falling. • BPBIO750 shall carry out a self-test to determine abnormalities in the blood pressure monitor automatically when the power is turned on; but you need to have experts inspected regularly every two years in order to maintain performance and safety.

  • Page 17: Blood Pressure Test

    Blood Pressure Test A. Precautions for Measurement Caution User should rest at least 5 to 10 minutes before the test. • Do not roll up the user’s sleeve, but take off thick clothes. • User should sit up straight in the chair. •...
  • Page 18 * Relax while sitting up straignt. Caution If an emergency occurs during the test, press Start/Stop button or button on the front bottom of • the BPBIO750. The cuff will release automatically. Emergency stop button BPBIO750_manual_ENG_A_190522.indd 16 2019-06-24 오전 10:23:10...
  • Page 19 * Please consult your physician for accurate diagnosis. 8. Others The Start/Stop button at the bottom right of the back of the BPBIO750 also allows you to proceed with the test, which can be useful when the administrator is conducting a blood pressure test behind the BPBIO750.

  • Page 20: Test Posture

    Sit as close as possible to the BPBIO750 * Be sure to place the elbow in the elbow groove before starting the test. * Take off thick clothes, and don’t roll up the sleeves.

  • Page 21: Transportation And Storage

    III. Transportation and Storage A. Cautions during Transportation To transport BPBIO750 safely, two people should keep the equipment parallel to the ground. Caution Keep the equipment horizontal while transporting. • BPBIO750_manual_ENG_A_190522.indd 19 2019-06-24 오전 10:23:12...

  • Page 22: Repacking Instructions

    After then, put the equipment in the package box, insert the packing pad and close the package box. Package Protection Vinyl Cuff Fixing Pad Packing pads C. Transportation and Storage Environment BPBIO750 should be transported or stored under the following conditions. Temperatures range -10 to 70ºC (14 to 158ºF) Relative humidity 10 to 80% RH (No Condensation)

  • Page 23: Faq

    Frequently asked questions and answers for BPBIO750 are as follows. If a problem persists even after checking below, please contact Customer Service Center of InBody. InBody Customer Service Center (+82-80-501-3939) A. Error Code The error messages can be displayed on the screen if the error occurrs during the test.
  • Page 24 Caution Repair and inspection can only be done by InBody personnel. • For repair or inspection, please contact Customer Service Center (+82-80-501-3939) of InBody Co., Ltd. Note Please record error messages that appear. It may be useful for Product Support.

  • Page 25: Regarding The Test

    C. Regarding the Test If problems cannot be resolved with the information below, please contact InBody. Question Answer · Test result are incorrect. · The arm and heart are not aligned during the test. Adjust the height of the chair to align the arm and heart. Correct testing posture. Incorrect testing posture. The arm is higher than the heart. Blood pressure value will be measured lower.
  • Page 26 It is recommended to not test within at least 1 hour. · Can results vary · BPBIO750 can operate at 10ºC to 40ºC. However, if the user feels that the depending on the temperature is low or high, this feeling makes the blood vessels expand or testing environment and contract, so it will ultimately affect the blood pressure results. It is recommended...

  • Page 27: Others

    Others * BPBIO750 was manufactured by the quality control procedure of InBody Co., Ltd. InBody Co., Ltd. complies with ISO9001 and ISO13485 which are international quality management systems. * This equipment satisfies the common standard for electrical and mechanical safety of medical devices and the common standard for the safety of medical devices. A. Exterior and Functions The names and functions of each part of BPBIO750 are as follows: * Please check each component of the system for damage prior to installation.

  • Page 28: Safety Information

    • system-shall comply with the standard IEC60601-1 and/or IEC60601-1-1 harmonized national standard or the combination. If in doubt, contact qualified technician or your local representative. B. Safety Information * The BPBIO750 is manufactured according to the quality management procedure of InBody. InBody complies with the ISO9001 and ISO13485 which are international quality management systems. * This equipment satisfies the IEC60601-1 (EN60601-1), an international safety standard for electronic medical equipment. This equipment also satisfies the IEC60601-1-2 (EN60601-1-2), an international standard for electromagnetic conformity. * This equipment has been tested and found to comply with the limits for medical devices in EN 60601-1-2.

  • Page 29: Product Classification

    Other Symbols Complies with AAMIES 6060-1 European conformity CSA-C22. 2 No.60601-1 Manufacturer Serial number Authorized representative in the Alternating current EUROPEAN COMMUNTY Operating instructions Disposal of old Electrical & Electronic Equipment (Application in the European Union and other European countries with separate collection system.) This symbol indicates that this product shall not be treated as household waste.

  • Page 30: Specifications

    D. Product Specifications Test Instructions Oscillometric Test range Pressure: 0 to 300 mmHg Pulse: 30 to 240 bpm Degree of precision Pressure: ± 2mmHg Pulse: Within ± 1.5% Test result Systolic blood pressure, diastolic blood pressure, pulse rate, pulse pressure, mean blood pressure, rate pressure product Test Time Approx.
  • Page 31 BPBIO750_manual_ENG_A_190522.indd 29 2019-06-24 오전 10:23:21...
  • Page 32 ©2019 InBody Co., Ltd. All rights reserved. BM-ENG-H2-A-190522 BPBIO750_manual_ENG_A_190522.indd 30 2019-06-24 오전 10:23:21...
