Summary of Contents for GOLDENSEA UV UVS4
- Page 1 USER GUIDE...
- Page 2 USER GUIDE- WARNINGS Improper use of this product may cause damage to skin and eyes This device may only be used by trained personnel Before operating this product the operator must read the user guide and be aware of all the risks associated with this product and best practices for using it Never enter the disinfection area when the product is in operation and the red LED is illuminated...
- Page 3 SAFETY BY DESIGN Motion Detection Audible/ Visual Alarms Delayed Start Time Fall Auto Protect* *UVS4, UVP36, UVM216, UVM432, UVAIR216 are fitted with this sensor...
- Page 4 SAFETY BY DESIGN Included Warning Sign Included UV Safety Glasses...
- Page 5 SAFETY BY DESIGN EVEN THOUGH ALL GOLDENSEA UV PRODUCT HAVE BUILT IN SAFETY FEATURES IT IS ESSENTIAL THAT ALL OPERATORS AND COMMERCIAL REPRESENTATIVES UNDERSTAND THE BEST PRACTICES AROUND USING THESE PRODUCTS!
- Page 6 USER GUIDE- PREPARE • Ensure unit is on a stable surface or properly wall mounted • Confirm disinfection area is clear of LIVING BEINGS PRIOR TO PROCEEDING • Wear the supplied UV glasses • Place supplied warning sign on outside of door and use use additional signs if required •...
- Page 7 USER GUIDE- SETUP 1. Plug the unit into an electrical outlet, do not modify/ alter the electrical connection of the product in anyway 2. Turn on the product by setting the I/0 rocker switch to I. The green LED will illuminate.
- Page 8 USER GUIDE- ACTIVATE 1. Press the start button 2. Once the start button is pressed an audible alarm will sound and a red LED light will flash for the duration of the delayed start time 3. YOU MUST EXIT THE DISINFECTION AREA IMMEDIATELY 4.
-
Page 9: End Of Cycle
USER GUIDE- END OF CYCLE 1. Once the disinfection process has ended, the red LED light will turn off and be replaced by the green LED light. This will indicate that it is now safe to enter the room 2. Upon entering the room, open windows to ventilate area 1. - Page 10 USER GUIDE- INTERRUPTION OF CYCLE 1. If the disinfection cycle is interrupted due to the motion sensor being activated, the unit will sound an alarm tone until an operator resets the unit 1. The unit may be reset by selecting the relevant timing cycle followed by the start button 2.
- Page 11 USER GUIDE- INFO 1. Unit is most effective when placed in line of sight of surface to be disinfected 2. Ensure placement of unit allows for greatest coverage 3. If necessary add more units at different points in the disinfection area 4.
- Page 12 REMEMBER NEVER ENTER THE DISINFECTION AREA WHEN THE PRODUCT IS IN OPERATION, THE ALARM BUZZER IS SOUNDING AND THE RED LED IS ILLUMINATED...
- Page 14 * Disinfection Area/ Time calculated based on a room height of 2.5m and targeting x pathogen. Different variables will result in changed area sizes. Please consult the GOLDENSEA UV Calculator for more information. ^ Box has a surface area 200 cm and 5 mins is enough time destroy/ neutralise all know pathogens at present.
- Page 15 DELAY START TIME CHART Delay Start Time UVS4 30 seconds UV-BOX UVP36 30 seconds UVL72 2 minutes UVL150 2 minutes UVL220 2 minutes UVT72 2 minutes UVM216 3 minutes UVM900 3 minutes...
