GOLDENSEA UV UVL220 Quick Start Manual

Hide thumbs Also See for UVL220:
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING! POSSIBLE RISK OF INJURY TO EYES AND SKIN.
• Hazardous optical radiation may be emitted from the light source. Do not look
at an operating lamp. It may be harmful to the eyes.
• UVC is emitted from the light source. Eye or skin irritation may result from
exposure. Use appropriate shielding.
• IR may be emitted from the light source. Do not look at operating lamp.
CAUTION!
• To avoid eyes and skin exposure to UV light, it is forbidden for animals, plants
and all personnel to be present when the UV lamp is on.
• Always disconnect mains supply before removing any fixture covers.
• Keep this device away from rain and moisture.
QUICK START GUIDE
UVL220
www.goldenseauv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UVL220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GOLDENSEA UV UVL220

Summary of Contents for GOLDENSEA UV UVL220

  • Page 1 QUICK START GUIDE UVL220 WARNING! POSSIBLE RISK OF INJURY TO EYES AND SKIN. • Hazardous optical radiation may be emitted from the light source. Do not look at an operating lamp. It may be harmful to the eyes. • UVC is emitted from the light source. Eye or skin irritation may result from exposure.
  • Page 2 Thank you for purchasing a GOLDENSEA UV product. This manual is a quick operation guide to get you started. For more information, please always refer to the full version user manual provided. Before unpacking, please check and be sure that the package is in good condition with no damage on the carton during transportation.
  • Page 3 • For safety reasons, the device was designed with a motion sensor: if the working device detects any movement within 3m, it will immediately deactive and a continuous audible dual beep and flashing red and green LED indicator lights will engage. •...
  • Page 4 Guangzhou Haoyang Electronic Co., Ltd. E-mail: support@goldenseauv.com; Tel: +86 20 3996 6388 Addr: No.109 Haiyong Road, Shiji Town, Panyu Zone, Guangzhou, China. 511450...
  • Page 5 UVL220 USER MANUAL KEEP THIS MANUAL FOR FUTURE NEEDS...

  • Page 6: Table Of Contents

    Thank you for purchasing a GOLDENSEA UV product. You have acquired a powerful and versatile device. We are confident that you will be satisfied with our excellent products and service. For your own safety, please read this user manual carefully before installing and operating the device.
  • Page 7 www.goldenseauv.com Voltage Input: AC 100-240V~, 50/60Hz; Power: 220W; Product Size: 491x76x594mm This UV lamp is only for commercial use in non-residential locations, such as in the hotels, schools, factories, theaters, gymnasiums, restaurants, offices, etc., it shall only be used by professional person. The warning sign as below shall be shown on the way to the fixture during operation.

  • Page 8: Manual Operation

    www.goldenseauv.com 1. Manual Operation (control panel) 1) Close all the doors and windows. 2) Plug-in and power on: press the power switch <I/O> to <I>, the power indicator turns on green. 3) Select time setting <30 mins>, <60 mins> or <120 mins> by the Time Setting touch key, the touch key indicator light turns on.

  • Page 9: Motion Sensor Operation(If The Lamp With Motion Sensor)

    www.goldenseauv.com Start 3. Motion Sensor Operation (if the lamp with Motion Sensor) 1. Turn on the UV lamp, select the disinfection time and start, leave the room, after 2 minutes alarming (Di….Di…Di….), the UV lamps will switch on automatically, the motion sensor will be activated.

  • Page 10: Suggestion For Disinfection Time

    www.goldenseauv.com According to the guideline, indoor spaces should be disinfected with UV light with an intensity of over 1.5 watts per square meter. An UV lamp can disinfect objects within one meter for at least half an hour. Longer exposure to radiation is needed when the temperature indoors is below 20°C or above 45°C and relative humidity is over 60%.

  • Page 11: Product Overview

    www.goldenseauv.com ATTENTION – RISQUE D’INCENDIE CAUTION: TO REDUCE THE RISK OF FIRE UTILISER UNIQUEMENT LES LAMPES USE ONLY _TUV PL-L, 36W,0.44A_ LAMPS _TUV PL-L, 36W,0.44A Suitable for damp locations CONVIENT AUX EMPLACEMENTS HUMIDES UV-C RISK GROUP 3 GROUPE DE RISQUE UV-C 3 WARNING: UV-C emitted from this AVERTISSEMENT UV-C émis par ce product.

  • Page 12: Dimensional Drawings

    www.goldenseauv.com 8. Dimensional Drawings 9. Installation Instructions 9.1 Installation of Floor Bracket Steps: 1. Take the device and the floor brackets out of the package. 2. Align the screw holes of the floor brackets with the screw holes at the bottom of the device.
  • Page 13 www.goldenseauv.com 9.2 Wall Mounting wall Steps: 1. Mount 2 screws (M4) on the wall with a distance of 422mm. 2. Mount the device onto the 2 screws using the 2 hooks of the device (as shown). 3. Attach a safety cable (not included) between the handle of device and a fixing point on the wall.
  • Page 14 www.goldenseauv.com 9.4 Installation of Tripod Bracket (optional) Steps: 1. Align the screw holes of the tripod bracket with the screw holes at the bottom of the device. 2. Fix the tripod bracket to the device with 2 screws (M4x10mm). 3. Install your tripod to the tripod bracket with corresponding screws. 9.5 Installation of Rotating Bracket (optional) Steps: 1.

  • Page 15: Replacing The Uv Tube

    www.goldenseauv.com 10. Replacing The UV Tube To maintain the sterilizing efficacy, the UV tube needs to be replaced after 9,000 hours of use. Steps: 1. Wait for UV tube to cool down (to avoid scalding) after switching off the device. 2.

  • Page 16: Troubleshooting Tips

    www.goldenseauv.com 11. Troubleshooting Tips 11.1 What to do if the device doesn’t work? 1. Ensure the device is plugged into a working wall socket. 2. Ensure the plug is wired correctly and terminal well-connected. 3. If you still have issues with the device, please contact your local dealer or our customer service for assistance.

  • Page 17: Features

    www.goldenseauv.com 12. Features Light Source • Lamp: TUV PL-L 36W/4P 1CT/25 (PHILIPS) HNS L 36W 2G11 GFT36DL/2G11/SE/OF PURITEC UV-C Germicidal Low Pressure Lamp (OSRAM) • Extremely long Life: up to 9,000 H Features • Delayed start (2-min delayed start) • Motion sensor •...

  • Page 18: Cleaning And Maintenance

    www.goldenseauv.com Reflector Included Floor Bracket Included Warning Sign Included Tripod Bracket Included Safety Cable Optional Rotating Bracket Optional UV Irradiance Meter Optional 13. Cleaning and Maintenance 1. To ensure the device remains in good condition and does not fail prematurely, regular maintenance, cleaning and checks are required.

  • Page 19: Service

    www.goldenseauv.com 14. Service For all service needs, please contact your local authorized dealer or GOLDENSEA customer service. Our contact details are: Email: support@goldenseauv.com Tel: +86 20 3996 6388 Address: No.109 Haiyong Road, Shiji Town, Panyu Zone, Guangzhou, China. 511450 Errors and omissions for all information given in this user manual are expected. All information is subject to change without prior notice.
