Parker B548 Installation & Service Instructions

Pneumatic Division
Richland, Michigan 49083
269-629-5000
WARNING
!
To avoid unpredictable system behavior that can cause personal
injury and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected
to this product before installation, servicing, or conversion.
• Operate within the manufacturer's specified pressure,
temperature, and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical
supplies (when necessary) should be connected and the product
tested for proper function and leakage. If audible leakage is
present, or the product does not operate properly, do not put
into use.
• Warnings and specifications on the product should not be
covered by paint, etc. If masking is not possible, contact your
local representative for replacement labels.
CAUTION
!
Polycarbonate bowls, being transparent and tough, are ideal for use
with Filters and Lubricators. They are suitable for use in normal industrial
environments, but should not be located in areas where they could be
subjected to direct sunlight, an impact blow, nor temperatures outside
of the rated range. As with most plastics, some chemicals can cause
damage. Polycarbonate bowls should not be exposed to chlorinated
hydrocarbons, ketones, esters and certain alcohols. They should not
be used in air systems where compressors are lubricated with fire-
resistant fluids such as phosphate ester and diester types.
Metal bowls are recommended where ambient and/or media conditions
are not compatible with polycarbonate bowls. Metal bowls resist the
action of most such solvents, but should not be used where strong
acids or bases are present or in salt laden atmospheres. Consult the
factory for specific recommendations where these conditions exist.
TO CLEAN POLYCARBONATE BOWLS USE MILD SOAP AND
WATER ONLY! DO NOT use cleansing agents such as acetone,
benzene, carbon tetrachloride, gasoline, toluene, etc., which are
damaging to this plastic.
WARNING
!
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Introduction
Follow these instructions when installing, operating, or servicing the
product.
Application Limits
These products are intended for use in general purpose compressed
air systems only.
Installation & Service Instructions
IS-B548
B548 Miniature Integral
Filter / Regulator Series
ISSUED: February, 2005
Doc. #ISB548, ECN #050142, Rev. 1
Maximum Recommended Pressure Drop:
Particulate Filter
Operating Pressure Maximum
Polycarbonate Bowl
Metal Bowl
Piston Drain
Operating Temperature Range
Polycarbonate Bowl
Metal Bowl
Piston Drain
Symbols
➤
Filter / Regulator
Installation
1. The Filter / Regulator should be installed with reasonable
accessibility for service whenever possible – repair service kits
are available. Keep pipe or tubing lengths to a minimum with
inside clean and free of dirt and chips. Pipe joint compound
should be used sparingly and applied only to the male pipe –
never into the female port. Do not use PTFE tape to seal pipe
joints – pieces have a tendency to break off and lodge inside
the unit, possibly causing malfunction. Also, new pipe or hose
should be installed between the Filter / Regulator and equipment
being protected.
2. The upstream pipe work must be clear of accumulated dirt and
liquids.
3. Select a Filter / Regulator location as close as possible to the
equipment being protected.
4. Install Filter / Regulator so that air flows into port labelled "IN"
on body.
! WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF
THE PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR
RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY
AND PROPERTY DAMAGE.
This document and other information from The Company, its
subsidiaries and authorized distributors provide product and/or
system options for further investigation by users having technical
expertise. It is important that you analyze all aspects of your
application, including consequences of any failure and review the
information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and
applications for these products or systems, the user, through its
own analysis and testing, is solely responsible for making the final
selection of the products and systems and assuring that all
performance, safety and warning requirements of the application
are met.
The products described herein, including without limitation, product
features, specifications, designs, availability and pricing, are subject
to change by The Company and its subsidiaries at any time
without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR
INCLUSION IN EQUIPMENT / MAINTENANCE MANUALS THAT
UTILIZE THESE PRODUCTS.
REPRESENTATIVE.
kPa PSIG bar
70 10 0.7
kPa PSIG bar
1034 150 10.3
2068 300 21.0
1207 175 12.0
Max. 49°C (120°F)
Max. 82°C (180°F)
Max. 65.6°C (150°F)
➤
CONTACT YOUR LOCAL
