  • Page 2: Table Of Contents

    Table of Contents NOTES BEFORE USE ... 2 ...2 NSTALLATION ...2 ONNECTING TO OWER ...2 AINTENANCE ELIVERING DISPLAY DJUSTING DISPLAY ...3 GETTING STARTED... 5 ... 6 ONTROL UTTONS ...7 NSTALLATION LCD P DJUSTING ANEL OSD F ... 8 ELECTING EATURES Brightness &...
  • Page 3: Notes Before Use

    Installation Do not cover or block the vent at the back of the LCD display. Keep LCD display away from direct sunlight or heat source, e.g., electrical heater or radiator. Avoid dust, mechanical vibration or shock. Connecting to Power Use correct type of power cord according to local specifications. Connect to a source near your LCD display.
  • Page 4: Adjusting Your Lcd Display Viewing Angle

    Adjusting Your LCD display Viewing Angle You can adjust your LCD display between 5°~25° by holding the top of the panel with both hands and pushing back and forth to adjust the viewing angle to the desired angle. Base Lock If you want to mount your LCD panel on the wall or save space for transportation, you can fold the base up and lock it with the patent pending base lock.
  • Page 5 When you open the carton of your LCD panel, the default position of the lock is at Base Lock. If you want to release the base, turn the lock counterclockwise to Base Release position and release the lock, it will automatically switch to the Neutral position. Now you may easily unfold the base.
  • Page 6: Getting Started

    After you have unpacked your LCD display, make sure that the following items are included in the package. LCD display Adaptor (Must use one of the following adaptors: Linearity LAD6019AB5, Li Shin LSE9901B1260) Power cord D-sub 15-pin VGA cable (*1) DVI-D digital cable (*1) Floppy/CD-ROM (containing Windows information file and user’s manual) Getting Started...
  • Page 7: Control Buttons

    Control Buttons Front View ON/OFF Button Push once to turn your LCD display ON and push again to turn it OFF. Power LED The power LED will turn to green under normal operation and orange when in standby mode. Auto Adjustment The auto adjustment function will automatically tune your LCD display to the optimal performance, including screen size, color, brightness and contrast.
  • Page 8: Installation

    Installation Connecting LCD Display to PC (Analog)— Remove all the packages from the panel. Place your LCD display in a suitable place. Make sure that there is enough space for adjustment, especially the rear of the panel. Turn off your PC and connect the D-sub 15-pin VGA cable included in the package to the VGA port on your PC.
  • Page 9: Adjusting Your Lcd Panel

    Adjusting Your LCD Panel In the OSD menu, you will find all kinds of features to help you adjust your LCD display to the optimal performance. Important! Though manual adjustment of the LCD display is available, we strongly recommend that you use the panel’s auto adjustment function. This will automatically tune your LCD display to the optimal performance.
  • Page 10: Osd Transparency

    OSD Transparency Select Transparency OSD in the OSD Adjust menu to adjust the transparency of OSD window. Push button to switch. Phase & Clock Select Clock and Phase in the Display Adjust menu to modify the distortion of video signal. Push button to adjust value.
  • Page 11: Recall

    Attention! For optimal performance of your LCD panel, set mode to TEXT when the resolution is 720x400 or 720x350 pixels and to GRAPHIC when the resolution is at 640x350 or 640x400 pixels. Recall Select Recall to reset all features to default settings. Push button to Recall.
  • Page 12: Warning Messages And Troubleshooting

    Warning Messages and Troubleshooting Warning Messages When a warning message appears on the screen, check the following items to locate the problem affecting your LCD display. NO SIGNAL INPUT NO VIDEO SIGNAL FROM ANALOG INPUT NO VIDEO SIGNAL FROM DIGITAL INPUT When no input signal is detected from any input ports.
  • Page 13: Troubleshooting Guide

    Troubleshooting Guide Symptoms • No display • Power LED is off. • No display • Power LED is amber • Blurred text display • No center screen. • Missing lines. • Red, green, blue or black spots on the screen. Check •...
  • Page 14: Specification

    Specification Size Panel Resolution (max.) Frequency Input Signal Pixel Clock (max.) Connector Power Supply Swivel Range Adjustable Weight Power Consumption Size Panel Resolution (max.) Frequency Input Signal Pixel Clock (max.) Connector Power Supply Swivel Range Adjustable Weight Power Consumption *The above specifications are subject to change without notice. 17”...
  • Page 15: Canada

    This FCC Class-B compliant digital device complies with the Interference-Causing Equipment Regulations of Canada. FCC Declaimers This device complies with Section 15 of the FCC listing. The operation procedures must meet the following conditions: (1) this device must not cause any damaging interference; and (2) this device must accept any received interference, including any unpredictable interference that may possibly occur.
  • Page 16: Tco'95

    TCO'95 Congratulations! You have just purchased a TCO'95 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 17 Current information regarding TCO'95 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ TCO’95 is a co-operative project between TCO (The Swedish Confederation of Professional Employees), Naturskyddsforeningen (The Swedish Society for Nature Conservation) and NUTEK (The National Board for Industrial and Technical Development in Sweden).
