Table of Contents PRECAUTIONS... 2 ...2 NSTALLATION ARNING ON POWER CONNECTION ...2 ARNING ON TILT ...3 AINTENANCE ...3 RANSPORTATION GETTING STARTED ... 4 ... 4 ACKAGE ONTENTS DENTIFYING ARTS AND ONTROLS ...7 ETUP NSTALL INFORMATION FILE FOR CUSTOMIZING YOUR MONITOR ...9 OSD M ... -
Page 3: Precautions
Installation • Do not cover or block the ventilation holes in the case. • Do not install the monitor near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock. -
Page 4: Maintenance
Maintenance • Clean the cabinet, glass, and controls with a soft cloth lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent, such as alcohol or benzene. • Do not rub, touch, or tap the surface of the screen with sharp or abrasive items such as a pen or screwdriver. -
Page 5: Getting Started
Package Contents Before using this monitor, check the following items are included in your carton box: • Monitor (*1) • Power adapter (*1) • Power cord (*1) • D-sub 15-pin VGA signal cable (*1) • Floppy/CD-ROM (containing Windows information file and user’s manual) Getting Started... -
Page 6: Identifying Parts And Controls
Identifying Parts and Controls Power switch Turns the monitor on or off. LED indicator The indicator lights up in green when the monitor is turned on, and lights up in orange when the monitor is in power saving mode. AUTO button Adjust the picture position and performance automatically. - Page 7 DC +12V Power inlet Provides +12V DC power to the monitor. VGA-In D-sub 15-pin connector for VGA signal. Fold-lock Press fold-lock on the stand of the monitor while you fold the stand back for storage or transportation. Rear View...
-
Page 8: Setup
Setup Please follow the steps one by one to setup your monitor. Fold the stand of monitor and split the dust-proof plastic sheet Fold the stand out, so you can locate the monitor on the table. Split the dust-proof plastic sheet from the screen surface of monitor. Connect the monitor to the computer or video source With the computer or other video source switched off, connect the video signal cable to the monitor. -
Page 9: Install Information File For Microsoft Windows 95/98/2000/Me/Xp
Turn on the monitor and computer or video source Turn on your computer or other video source. And press to turning on your monitor. You should see the picture on your monitor now. If not, please check the “Warning Signal and Troubleshooting” section of this user manual for details. -
Page 10: Customizing Your Monitor
This section covers the LCD monitor’s On-Screen Display (OSD), and front panel control buttons. Important! Though manual adjustment of the LCD panel is available, we strongly recommend you to use the auto adjustment function of the panel. It will automatically tune your LCD panel to the optimal performance. -
Page 11: Osd Menus
OSD Menus Brightness Adjustment Contrast Adjustment Horizontal Position Adjustment Vertical Position Adjustment... - Page 12 Sharpness Adjustment OSD Transparency Adjustment Phase Adjustment Clock Adjustment...
- Page 13 Color Temperature Selection P.S. The color temperature of RGB can be adjusted in case of entering “ USER ”sub menu. Horizontal OSD Position Adjustment Vertical OSD Position Adjustment Graphic/Text Selection P.S. Suggest the user select“ Text ”sub menu in case of the resolution being 640×350 or 640×400.
- Page 14 Recall Selection P.S. Suggest the user to use“ Recall ”icon, if the user doesn’t satisfy with the adjustment. Language Selection Auto adjustment Selection Exit Selection...
-
Page 15: Warning Messages And Troubleshooting
Warning Messages and Troubleshooting Warning Messages If the message appears on the screen CAN NOT DISPLAY THIS INPUT SIGNAL NO SIGNAL INPUT MAIN CONTROL MENU LOCKED/UNLOCKED NO VIDEO SIGNAL FROM VGA-IN WAIT FOR AUTOMATIC ADJUSTMENT Check the items The input signal is not acceptable by the monitor. •... -
Page 16: Troubleshooting
Troubleshooting Symptom • No picture • LED power indicator is not lit • No picture • The LED power indicator is amber color • The texts are not solid • • Screen image is not Centered properly • Some lines missing •... -
Page 17: Technical Features And Specifications
Technical Features and Specifications Power Saving Function This monitor meets the power-saving guidelines set by VESA and Energy Star, as well as the more stringent NUTEK. If the monitor is connected to a computer that is VESA DPMS (Display Power Management Signaling) compliant, the monitor will automatically reduce power consumption in the three stages as shown below. -
Page 18: Specifications
Specifications Electrical characteristics Screen size Pixel format Horizontal frequency Vertical frequency Maximum pixel clock Connections Power Consumption Physical characteristics Weight Tilt angle Temperature Humidity 15.0” (381mm) diagonal 1024 x 768 vertical stripe 30kHz – 60kHz 50Hz – 75Hz 80MHz Power: 3-Pin AC Plug 100 ~ 240V, 47~63Hz <... -
Page 19: Regulations
FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 20: Tco'95
TCO'95 Congratulations! You have just purchased a TCO'95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. - Page 21 Email (Internet): development@tco.se Current information regarding TCO'95 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ TCO’95 is a co-operative project between TCO (The Swedish Confederation of Professional Employees), Naturskyddsforeningen (The Swedish Society for Nature Conservation) and NUTEK (The National Board for Industrial and Technical Development in Sweden).
