Section B: Connecting the MPU5 to the Management Computer

→
What Will I Learn?
How to physically connect the MPU5 to the Management Computer
▶
≈

Parts List

22-Pin to RJ45 Receptacle
CBL-DATA-2001
Standard RJ45 Ethernet Cable
NO NDA REQUIRED
The export and/or the release of certain products, technology and software to non-US persons might
be subject to export restrictions. Please refer to the US export laws & regulations for details.
SOFTWARE SETUP: MANAGEMENT COMPUTER
Properly Configured Management Computer with Ethernet Port
