Parts List

22-Pin to RJ45 Receptacle
CBL-DATA-2001
22-Pin to USB 2.0 Type A Receptacle
CBL-DATA-2003
22-Pin to 6-Pin Push Pull USB Tether
CBL-DATA-2004
22-Pin to Audio and Video Out
CBL-DATA-3002
NO NDA REQUIRED
The export and/or the release of certain products, technology and software to non-US persons might
be subject to export restrictions. Please refer to the US export laws & regulations for details.
PHYSICAL SETUP: SIDE CONNECTORS
22-Pin to U94
CBL-AUD-0003
22-Pin to U-329
CBL-AUD-0001
22-Pin to U-328
CBL-AUD-0002
