Persistent Systems Wave Relay MPU5 Basic Operator Manual page 39

CBL-AUD-0002 22-Pin to U-328
CBL-AUD-0007 22-Pin to Audio and USB
2.0 Type A Female
CBL-AUD-2009 22-Pin to Audio and 6-Pin
Push Pull Android™ USB
Refer to the MPU5 Product Catalog for more information on MPU5 cables. If you still have ques-
tions, contact Persistent Systems.
✓
What Can I Do Now?
Identify which cable you need for your configuration
▶
Identify which side connector your cables attach to
▶
Connect a cable to a side connector
▶
NO NDA REQUIRED
The export and/or the release of certain products, technology and software to non-US persons might
be subject to export restrictions. Please refer to the US export laws & regulations for details.
PHYSICAL SETUP: SIDE CONNECTORS
PTT/EUD Connects to a headset via a U-328 connector.
PTT/EUD Connects USB accessories via a standard USB A
port and an audio accessory via a U-328 connec-
tor
PTT/EUD Connects an Android™ EUD or Screen and an
audio accessory via a U-328 connector
