Quick Reference:
LED Color Unit Status
Blue Booting
Yellow
Running, no neighbors
Green Running, neighbors
Red
Crypto Fail (No key or FIPS)
Orange Low Battery
Purple
Loading Firmware
? What do I do if my Power Knob does
not rotate?
Make sure that you are twisting it in the correct
1
direction (clockwise).
Make sure that no foreign objects are blocking the
2
rotation of the knob.
If the knob still does not rotate, it may be broken.
3
Contact Persistent Systems Support.
NO NDA REQUIRED
The export and/or the release of certain products, technology and software to non-US persons might
be subject to export restrictions. Please refer to the US export laws & regulations for details.
PHYSICAL SETUP: POWER
What do I do if the Power Knob does
?
not click when I twist it?
The Power Knob may be broken. Contact Persistent
1
Systems Support.
Ensure that the battery latch is not stuck in the
2
unlocked position.
