PHYSICAL SETUP: POWER

Powering On the Unit

Ensure that antennas, a RF module, and
1
an appropriate power source are connect-
ed.
WARNING!:
Antennas MUST be installed prior
!
to powering on the unit.
Locate the Power Knob on the top of the
2
unit.
PAGE 32 OF 176 03EN073 Rev. M
© 2010 - 2020 Persistent Systems, LLC – All Rights Reserved
3
Twist the Power Knob clockwise 1 click.
If the unit is powered and has turned on,
4
the LED on the top of the unit will glow
a color indicating unit status.
