4. FAQ & Trouble Shooting
Frequently Asked Questions
4.1 How to make a factory reset
There are three ways to make a factory reset:
1.Factory reset from keyboard, steps are:
a) Press and input password 123.
b) Find and select '13 Factory Reset'.
c) Press 'OK' key, then the phone will be restarted automatically and factory reset.
2.Factory reset through web, please refer to
3. Factory reset during rebooting, steps are:
a) Press '*' and '#' key immediately after plugging in the power adapter.
b) Wait for about 5 seconds, A20/A21/A20W/A21W will be reset to factory default setting after
rebooted.
4.2 Upgrade firmware under safe mode
If the phone could not start up normally, please upgrade firmware under safe mode. Steps are:
1. Build a TFTP server and set its IP address as 192.168.1.200.
2. Modify the software name as A20/A21/A20W/A21W.tar.gz . After decompression,modify the
app file name as A20/A21/A20W/A21W.FW and copy the firmware to the root directory of the
TFTP server.
3. Make sure the TFTP server and the phone are connecting with the same switch and reachable
to each other;
4. Keep pressing '#' key and start up the phone until the LCD displays 'Upgrading...';
5. The phone will download the firmware from the TFTP server;
6. After the download is done, the phone will upgrade automatically;
7. After the update is finished, the phone will start up with the factory configuration.
4.3 How to make direct IP call
When hook off/ pressing speaker or headset key,
1. Press soft key 'Num' until it switch to 'IP'.
2. Using '*' key to input '.'. If user wants to dial 192.168.1.100, then press 192*168*1*100.
3. After inputting the IP address, press dial key to dial it out.
