CQ-VS8380A AM/FM/SW Electronic Tuning Radio with Stereo Cassette Tape Player PART No. : 86120-52290 ID CODE : 57416 VEHICLE : COROLLA, PRONARD, ECHO, RAV4 DESTINATION : Middle and Near East PRODUCED AFTER : July, 2003 Specifications* General Cassette Player (YGFD04730)
CQ-VS8380A CONTENTS Page Page 1 FEATUERS 8 PACKAGE AND IC BLOCK DIAGRAM 2 SYSTEM BLOCK DIAGRAM 9 REPLACEMENT PARTS LIST 3 FRONT VIEW AND FUNCTIONS 10 EXPLODED VIEW (Unit) 4 REAR VIEW AND CONNECTORS 11 WIRING DIAGRAM 5 WIRING CONNECTION...
CQ-VS8380A 7 TERMINALS DESCRIPTION 7.1. Main Block No connection No connection IC601 : C2CBHG000067 No connection MSOUT TPS detection Port Description No connection No connection BEEP Buzzer output No connection BIT3 Tape mode SW MS-PL/FF MS mode selection BIT2 Tape mode SW T.LOAD...
CQ-VS8380A 9 REPLACEMENT PARTS Ref. Part No. Part Name & Description Remarks D712 YEADSR1544TL Diode LIST D713 YEADSR1544TL Diode D741 B0BC8R100002 Diode Notes : 1. Be sure to make your orders of replacement parts CAPACITORs according to this list. C100 YECUZ1H103KX Ceramic, 0.01µF 50WV...
Page 11
CQ-VS8380A Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks Chip, 43kΩ Ω Ω Ω 1/16W C313 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV R156 ERJ3GEYJ433V Chip, 56kΩ Ω Ω Ω 1/16W C321 ECEA1CKS100I Electrolytic, 10µF 16WV...
Page 12
CQ-VS8380A Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks Chip, 4.7kΩ Ω Ω Ω 1/16W R617 ERJ3GEYJ472V Chip, 4.7kΩ Ω Ω Ω 1/16W R618 ERJ3GEYJ472V NEON TUBE Chip, 4.7kΩ Ω Ω Ω 1/16W...
Page 13
CQ-VS8380A Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks XSB26+5FX Screw, M2.6x5mm RESISTORs YEJT03009 Screw, M3x8mm Chip, 560Ω Ω Ω Ω 1/10W R901 ERJ6GEYJ561 YEJT03013 Tapping Screw, Chip, 560Ω Ω Ω Ω 1/10W...
6 TAPE PLAYER PARTS Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks CONNECTORs YEAE012385 Connector, 17P [E8790A] Dolby Block YEAESLW05R1 Connector, 5P IC´s and TRANSISTORs C1BB00000100 Q401 YEANC114YKX Transistor SWITCHEs K0J1CB000001 Switch YEAS07174 Switch CAPACITORs...
Page 27
Ref. Part No. Part Name & Description Remarks YGP0PT8790A0 Dolby P.C.B. Ass´y YGP9FZ2973 Head Ass´y YGFX0462105 Lever YGFX0052478 Vibration-proof Spring YGFX0052477 Spring YGFX239470 Cassette Guid Plate YGFX0462097 PRO Change Plate YGFX0031031 Idler Gear Plate (F) Ass´y YGP0FX3845 Main Motor Ass´y YGFX0052474 Lack Return Spring YGFX218305...
