Toyota 00016-00950 Manual

Doc. 03.99.00
TOYOTA
Part Number:00016-00950
Accessory Code: RX1000
Conflicts
1. Vehicles with factory XM radio.
2. Vehicles without touch-screen radio.
Kit Contents
Item # Qty
1 1 XM Module
2 1 XM Tuner Module
3 1 Wiring Harness
4 1 Hardware Bag
5 1 XM Antenna
6 2 24" Wire Ties
Hardware Bag Contents
Item # Qty Reqd.
1 24 8" Black Cable Ties
2 2 Red T-Taps
3 2 Blue T-Taps
4 2 Black T-Taps
5 1 2" x 2" Foam Mounting Pad
6 1 3.5" x 6" Foam Pad
7 6 1 1/4" x 2 1/2" Foam Pad
8 2 1" x 1" Double Side Mounting Tape
9 4 1/2" Philips Screws
Recommended Tools
Safety Tools
Special Tools
Installation Tools
Phillips Screwdriver
Ratchet w/ Extension
Diagonal Wire Cutters
Flashlight
Torque Wrench (48 in. lbf.)
Protective Tape
Power Drill
Special Chemicals
VDC Approved Cleaner
Southeast Toyota Distributors, LLC
Business Partner: L95
Corolla 2015
Description
Description
Straight-Slot Screwdriver
10 mm Socket
Common Pliers
Nylon Trim Tool
Electrical Tape
1/8" Drill Bit
PIO / DIO
Vehicle Service Parts
(May be required for reassembly)
Part Number Qty
00016-00950-01 1 Main Wiring Harness
00016-00950-02 1 Pairing Button
00016-00950-03 1 XM Antenna
00016-00950-04 1 XM Tuner
00016-00950-05 1 Hardware Bag
00016-00950-06 1 Main Control Module
General Applicability
1. Radios without factory XM
Legend
STOP: Damage to the vehicle may occur. Do not
STOP
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CRITICAL PROCESS: Proceed with caution to
!
ensure a quality installation. These points will be
audited on a completed vehicle installation.
TOOLS AND EQUIPMENT: This calls out the spe-
cific tools and equipment required for this process.
REVISION MARK: This mark highlights a change in
installation with respect to a previous issue.
S SAFETY TORQUE: This mark indicates that torque
is related to safety.
SPECIAL NOTE:
After TMS and Safety mandated preparatory steps have
been taken, the installation sequence is the suggested
method for completing the accessory installation. In some
instances the suggested sequence is written for one associ-
ate to install and in others the sequence is given as part of a
team accessory installation. Unless otherwise stated in the
document, the associates may perform the installation steps
in any order to make the installation as efficient as possible
while maintaining consistent quality.
DIAGNOSTIC NOTE:
Diagnostic and troubleshooting information on this
accessory is available on SET Dealer Daily. Please
visit the service information section of SET Dealer
Daily for more information.
11/21/14
XM Satellite Radio
Description
Rev. - 11/20/2014
