Using Ethernet Multi-port Midspan Power Supply

To use an Ethernet multi-port midspan power supply, you must

connect the power supply to your network, as shown in the

following illustration.

The Ethernet multi-port midspan power supply from 3Com

connects to an existing Ethernet or Fast Ethernet infrastructure

with standard Category 5 or better cabling, and powers up to 24

IntelliJack devices. For complete installation instructions, see the

Ethernet multi-port midspan power supply documentation

located at www.3Com.com.

Connect the network data/voice/power cable to the IntelliJack

white cable, as shown in the following illustration.

Connect the network second data/voice/power cable (if

available) to the IntelliJack black cable, as shown in the following

illustration.
