OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
2016 Gees Mill Road, Suite 200, Conyers, GA 30013
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified Brands
suggests that if you are suspicious of damage to make a notation on the
delivery receipt. It will be the responsibility of the consignee to file a claim
with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
The EE is a floor-mounted, stationary,
steam jacketed kettle with an elec-
tronically controlled, self-contained,
electrically-heated steam supply and
appropriate controls, mounted on a
sturdy base. The kettle is available in
20 or 40 gallon (75 or 150 liters) ca-
pacities.
The body of the kettle is constructed of stainless steel, welded into one solid piece.
The kettle is furnished with 50 mm (2 in.) sanitary tangent draw-off valve (product
faucet) and a stainless steel strainer. Standard draw-off uses a compression disc
valve. Unit is provided with a one piece, hinged design dome style cover. It has a
steam jacket rated for working pressures up to 30 psi (206 kPa, 2.06 bar). Kettle
finish is 180 emery grit on the inside and #3 uniform finish on the outside.
The kettle is surrounded by insulated stainless steel sheathing. Stainless steel
panels enclose the controls. Three stainless steel, tubular legs support the unit.
Bullet feet on each of the legs can be adjusted to level the kettle.
A built-in steam generator, sized for the kettle capacity and heated by electric-
ity, delivers steam into the jacket. "Airless" operation of the steam jacket permits
READ,
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands recommends
referencing our product line websites, unifiedbrands.net, for the most updated product information and specifications. © 2020 Unified Brands. All
Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
This manual provides information for:
STEAM JACKETED KETTLE
MODELS EE-20 & 40
(CE) INTERNATIONAL
REFERENCES
NSF INTERNATIONAL
798 N. Dixboro Rd.
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
UNDERWRITERS LABORATORIES, INC.
333 Pfingsten Road
Northbrook, Illinois 60062
uniform, efficient heating at temperatures as low as 150°F (65.5°C) and as high
as 270°F (132°C). In addition to the electronic temperature control, the unit has a
low water cut-off, safety valve, and high-limit pressure switch as safety features. A
heating indicator light, pressure gauge, and sight glass are provided for monitoring
kettle operation.
A single electrical connection is required for installation. The unit may be ordered
for use with 230 VAC, 1 Phase, 50 Hz, or 400 VAC, 3 Phase, 50 Hz power.
Options available include:
1. 75 mm (3 in.) diameter tangent draw-off (product valve) (factory installed)
2. Perforated or solid disc strainer
3. Water fill faucets
4. Basket cooking system
5. Kettle brush kit
6. Gallon etch marks (factory installed)
PART NUMBER 177364, REV. C (10/20)
KLENZADE SALES CENTER ECOLAB, Inc.
370 Wabasha
St. Paul, Minnesota 55102
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
NFPA/70 - The National Electric Code
ZEP MANUFACTURING COMPANY
1310-T Seaboard Industrial Boulevard
Atlanta, Georgia 30318

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EE-20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Groen EE-20

  • Page 1 PART NUMBER 177364, REV. C (10/20) This manual provides information for: STEAM JACKETED KETTLE OPERATOR MANUAL MODELS EE-20 & 40 (CE) INTERNATIONAL IMPORTANT INFORMATION, KEEP FOR OPERATOR 2016 Gees Mill Road, Suite 200, Conyers, GA 30013 888-994-7636, fax 888-864-7636 unifiedbrands.net THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
  • Page 2: Inspection And Unpacking

    TO LIFT THIS WEIGHT SAFELY. Rim Height 940 mm (37 in) 940 mm (37 mm) Total Width 660 mm (26 in) 813 mm (32 in) Front to Back 972 mm (38¼ in) 1226 mm (48¼ in) OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 3: Installation

    1. Set the kettle in place and level it by turning the bullet feet to adjust leg length. Allow clearance around the unit for cleaning, maintenance and service. Now that the kettle has been installed, you should test it to ensure that the unit is operating correctly. OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 4: Operation

    Vacuum” in this manual. c. Turn on the electrical power to the unit. d. Turn on the main power switch on the control face. e. Turn the temperature knob to the desired setting. The heating indicator OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 5: Maintenance

    4. Rinse the kettle and draw-off valve parts thoroughly with hot water, then drain completely. 5. As part of the daily cleaning program, clean soiled external and internal surfaces. Remember to check the sides of the unit and control housing, underside of cover, etc. OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 6: Periodic Maintenance

    (35 kPa, 0.34 bar), release the trapped air and steam by pulling up the safety valve ring for about five seconds. Repeat this step three or four times. Then let the pull ring snap back into the closed position. OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 7: Sequence Of Operation

    Service Rep Only ground short or open element. If an If you have questions pertaining to the content in this manual, contact Unified element is defective, call Groen. X Brands at 888-994-7636. c. Voltage of main power source. X Safety valve leaks User a.
  • Page 8: Parts List

    Parts List (Keyed to Drawings and Photographs on the Following Pages) To order parts, contact your Groen Certified Service Agency. Supply the model designation, part description, part number, quantity and, where applicable, voltage and phase. DESCRIPTION PART NO. DESCRIPTION PART NO.
  • Page 9 Parts List FOR SAFETY VALVE & WATER FILL ASSEMBLY SEE PHOTOGRAPHS IN THIS SECTION. 22 23 24 25 OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 10 10.0 Parts List Parts List (Keyed to Parts List on Page 17) To order parts, contact your Groen Certified Service Agency. Supply the model disignation, part description, part number, quantity and, where applicable, voltage and phase. OM/SM-EE-CE OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 11 (2) Fill a mixing container with the 3. Jacket Filling and Water Treatment To order parts, contact your Groen Certified Service Agency. Supply the model disignation, part description, part measured amount of water req number, quantity and, where applicable, voltage and phase.
  • Page 12 Parts List OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 13: Wiring Diagram

    Wiring Diagram 400 VOLT, 3 PH OM-EE-20 & 40 (CE) INTERNATIONAL...
  • Page 14: Service Log

    Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-EE-20 & 40 (CE) INTERNATIONAL...
