T
ESTING THE
3
C
ONFIGURATION

Introduction

This chapter contains information on testing the
Configuration.

General Testing

IP Testing


Advanced Troubleshooting


General Testing
After configuring the OfficeConnect Remote 812 for
remote site connection(s), follow these steps to test the
connections.

Step 1: Check Interface Status

1 Be sure the DSL cable is connected to the OfficeConnect
Remote 812 and the phone jack, and then check the ADSL
Status LED on the front of the unit. It should be green or
blinking green.
2 If the unit is not in a location where you can see the LEDs,
go to the OfficeConnect Remote 812 Manager home page.
Select Monitor > Interface Status. The following table
should display:
Ensure that Oper Status of interface atm:1 is UP.
If the status of atm:1 is not UP, check the cable connection
to make sure it is securely plugged into the unit and check
