H3C MSR 20-20 Router Appearance
1 Front view
Figure 1 Front view of H3C MSR 20-20 router
(1) Power LED (PWR)
(3) ESM LED (ESM)
2 Rear view
Figure 2 Rear view of MSR 20-20 router
(3) (4)
(5)
(1) SIC slot2
(3) Grounding terminal
(5) Power switch
(7) Fixed Ethernet interface 1 (LAN1)
(9) Auxiliary port (AUX)
(11) CF card LED

Panel LEDs

The following table gives the features of H3C MSR 20-20 router LEDs:
Table 5 Front panel LEDs description of MSR 20-20 router
LED
PWR
SYS
(1) (2) (3)
(2) System LED (SYS)
(7)
(6) (8) (9) (10)
(2) SIC slot1
(4) Power receptacle
(6) Fixed Ethernet port0 (LAN0)
(8) Console port (CON)
(10) USB interface
(12) CF card interface
Description
Power LED:
ON means power is on.
OFF means power is off.
System operating LED:
Green and fast blinking means the system is booting.
Green and slow blinking means the system is operating normally.
Yellow and fast blinking means the system is malfunctioning.
Steady OFF means the system does not operate normally.
Router Model and Structure
(1) (2)
(11) (12)
11
