3Com Router 3030 Installation Manual page 8

8 C 1: I R 3000 DSL F
HAPTER NTRODUCING THE OUTER AMILY
4. ETH LED (LAN0)
5. ADSL active LED (ADSL ACT)
6. ADSL link LED (ADSL LNK)
7. System LED (SYS)
8. Power LED (PWR)
Figure 2 Router 3030 Rear Panel
1 3
2 4 8
5 6 7
9
1. Power switch
2. Power input socket
3. Console port (CON)
4. Ethernet port 0 (LAN0)
5. Ethernet port 1 (LAN1)
6. Ethernet port 2 (LAN2)
7. Ethernet port 3 (LAN3)
8. Grouding screw
9. ADSL port (ADSL ober POTS)
