Figure 6 Router 3032 Rear Panel

7 8

1. Power switch

2. Power input socket

3. Console port (CON)

4. Ethernet port 0 (LAN0)

5. Ethernet port 1 (LAN1)

6. Ethernet port 2 (LAN2)

7. Ethernet port 3 (LAN3)

8. Grounding screw

9. ADSL port (ADSL over ISDN)
